Electro-Voice EKX-12P-US 12 Inch Two-Way Powered Loudspeaker US Cord

ITEM #: EV-EKX-12P-US MFG #: EKX-12P-US

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Electro-Voice
Free Shipping with $49 Minimum Order

List Price:

$1,619.00

Our Price:

$899.00

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

EKX-12P-US - Overview

EV engineering and innovation working together for maximum sonic impact
The EKX series is the newest member of the Electro-Voice portable loudspeaker family, and combines legendary EV sound quality and reliability with the latest technology - all in a compact package suitable for a wide range of sound reinforcement scenarios, including musicians/DJs and live/club/installed sound applications.

The EKX series features eight models (four powered and four passive), including 12" and 15" two-way models and 15" and 18" subwoofers. EKX is positioned above the ZLX and ELX series and below the ETX series.

Ideal for portable and installed applications
Lightweight, compact 15-mm wood enclosures with internal bracing, durable EVCoat finish, eight M10 threaded mounting points (full-range models), aluminum pole-mounts, and all-metal handles. Subs feature large slot ports for low distortion and excellent bass extension, and are equipped with a metal grille reinforcement bar.

  • Features:

    • QuickSmartDSP features best-in-class processing, EV’s signature single-knob user interface, and intuitive menu navigation via LCD.
    • High-efficiency 1500 W Class D power amplifier delivers up to 132 dB peak SPL on the EKX-12P via high-sensitivity transducers designed and engineered by EV.
    • Intelligent thermal management with a variable-speed fan controlled by multiple onboard sensors, ensuring superior performance and reliability in demanding environmental conditions.
    • EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage.
    • Lightweight, compact 15-mm wood enclosure with internal bracing, durable EVCoat finish, eight M10 threaded mounting points, aluminum pole mounts, and all-metal handles.


  • Specifications:

    • Connector Type: (1) Stereo RCA input, (2) XLR/TRS combo jack, and (1) XLR link output
    • Coverage: (Nominal -6 dB) H 90 Deg.
    • Coverage: (Nominal -6 dB) V 60 Deg.
    • Crossover Frequency: 1.7 k Hz
    • Enclosure Material :15 mm, plywood with EVCoat
    • Frequency Response: (-10 dB) 50 Hz - 20 kHz Hz Full space measurement using the music DSP preset.
    • Frequency Response: (-3 dB) 60 Hz - 18 kHz Hz Full space measurement using the music DSP preset.
    • Grill: 18 AWG steel with powdercoat
    • HF Transducer: DH-1M 1-inch titanium compression driver
    • LF Transducer: EVS-12M 300 mm (12 in)
    • Maximum SPL: 132 dB dB Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
    • Power Consumption: 1.8 A Current rating is 1/8 power
    • Power Rating: 1500 W
    • Shipping Weight: 22.9 kg (50.49 lbs)
    • Suspension: (8) M10 threaded mounting points
    • Height: 14RU 607 mm (23.9")
    • Width: 375 mm (14.76")
    • Depth: 356 mm (14.02")
    • Weight Net: 18.8 kg (41.45 lbs)


  • GTIN:

    0800549772167
