Genelec 8320APM Smart Active Bi-Amplified Monitor - 4 Inch LF 50W - Analog Input - Producer Finish

ITEM #: GNC-8320APM MFG #: 8320APM

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$795.00

Our Price:

$725.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


8320APM - Overview

Easy enough to carry with you yet packed with today's most advanced monitoring technology, the 8320A will make the most of your recording environment, no matter where you choose to work.

Small but mighty, the two-way, Class-D bi-amplified 8320A blends a deceptively powerful 4-inch woofer with Genelec's renowned acoustic design expertise and world-leading Smart Active Monitoring (SAM) technology. Each SAM system is designed to adapt and assist, working with proprietary Genelec Loudspeaker Manager (GLM) 2.0 software to deliver a suite of ground-breaking functions. Allow AutoCal to ensure your monitoring system is perfectly calibrated to your listening environment, compensating for detrimental room influences to create a truly optimized monitoring solution. Use GLM 2.0 to manage up to 30 Smart monitors and subwoofers, allowing you to mix the way you want, from simple stereo to ambitious immersive audio setups. Delve deep into control options including full recall of settings for different listening positions.

All this combines with the color-free accuracy of the Minimum Diffraction Enclosure (MDE), and precise on- and off-axis frequency reproduction of the Directivity Control Waveguide (DCW). The result is the ideal small monitor to fit the way you work.

  • Features:

    • Smart Active Monitor (SAM) Systems
    • Directivity Control Waveguide (DCW) Technology
    • Minimum Diffraction Enclosure (MDE) Technology
    • Reflex Port Design
    • Optimized Amplifiers
    • Active Crossovers
    • Protection Circuitry
    • Intelligent Signal Sensing (ISS) Technology
    • Iso-Pod Stand
    • Versatile Mountings

  • Specifications:

    • Frequency range -6 dB: 55 Hz - 23 kHz
    • Accuracy of frequency response: ±1.5 dB (66 Hz - 20 kHz)
    • Maximum short term sine wave acoustic output on axis in half space, averaged from 100 Hz to 3 kHz: > 100 dB SPL
    • Maximum long term RMS acoustic output in same conditions with IEC weighted noise (limited by driver unit protection circuit): > 94 dB SPL
    • Maximum peak acoustic output per pair, at 1 m distance with music material: > 107 dB
    • Self generated noise level in free field on axis: < 5 dB (A-weighted)
    • Harmonic distortion at 85 dB SPL on axis: 50 - 200 Hz < 3 %; >200 Hz < 0.5 %
    • Drivers (Both drivers are magnetically shielded): Woofer: 105 mm (4 in) cone; Tweeter: 19 mm (3/4 in) metal dome
    • Weight: 7.0 lb
    • Height including Iso-Pod table stand: 9 1/2 in.
    • Dimensions (H x W x D): 9 1/16 in x 6 in x 5 5/8 in

      Amp
    • Bass amplifier short term output power: 50W
    • Treble amplifier short term output power: 50W
    • Total harmonic distortion at nominal output: <0.05%
    • Mains voltage: 100-240 VAC, 50-60 Hz
    • Power consumption (ISS active / idle / maximum): < 0.5 W / 3.0 W / 50 W

      Input
    • Crossover frequency: 2.9 kHz
    • Analog input (load impedance): XLR female (10 kOhm, balanced)
    • Analog input level for 100 dB SPL output at 1 meter: -6 dBu (adjustable in GLM software)
    • Maximum analog input: 24 dBu
    • GLM Control network connectors: 2 x RJ45

  • Item Includes:

    • 1x Genelec 8320APM Bi-Amplified Studio Monitor

  • Warranty:

    • 2-Year Warranty

  • GTIN:

    6438128100373
