Barix Instreamer ICE AAC/MP3 Analog Audio Over IP Encoder and Icecast Server

2018.9238P - Overview

• Features:

  • MP3, AAC encoding
  • Integrated Icecast server for up to 50 simultaneous web radio users
  • Line level input (stereo)
  • Supply voltage 5VDC


• Specifications:

  • Power Supply Input
  • External power adaptor, 100-240VAC, 10W
  • Male connector: 5,5 x 2,1 mm
  • 1 Ethernet Interfaces
  • RJ45 10/100 auto detect, IPv4, IPv6

    Audio Input
  • Stereo RCA / cinch connectors

    Audio formats
  • MP3, AAC mono and stereo
  • Sample rates 22.05/24/32/44.1/48Khz

    Headphone output
  • Female Jack 3.5 mm

    USB
  • Double USB connector type A female(for future use)

    RS-232
  • For meta data contribution

    Icecast
  • Integrated Icecast server: supports up to 50 subscribers
  • Source to external Icecast server

    HW/SW environment
  • Barix IPAM400
  • Linux with dual boot recovery and remote firmware update capability

    User Interface
  • Web interface for control, status and configuration
  • HW reset button, LEDs for status

    Case & Weight
  • Aluminum
  • 108x38x78.7mm (4.25x1.5x3.1 inch)
  • Weight 250g


  • Environmental
  • Operating Environment
  • 0 to +50°C / 32 to 122°F
  • 0 - 70% relative humidity, non-condensing
  • Storage Conditions
  • -20 to +70°C / -4 to 158°F
  • 0 - 70% relative humidity, non-condensing


• Warranty:

  • 2 years
