Kinefinity MAVO 6K Edge Full-Frame 3:2 CMOS Cinema Camera - Deep Gray - Body Only

ITEM #: KINE-A010-002-01 MFG #: KINE-A010-002-01

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$9,999.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


KINE-A010-002-01 - Overview

Introducing the Kinefinity MAVO Edge 6K, a powerful new full-frame cinema camera. Equipped with a 6K full-frame 3:2 CMOS imaging sensor capable of shooting in 6K 75fps and 4K 150fps based on the high-performance computing platform of the MAVO Edge, the camera features dual native ISO (800/5120) and excellent highlights under various sensitivity settings. MAVO Edge 6K has an internal motorized full-spectrum e-ND filter(0.6-2.4), and integrates industry-standard ports and dual SSD media slots, capable of recording Apple ProRes4444/XQ and uncompressed RAW onto recording media based on NVMe M.2 2280 SSD. Weighing at only 3.6lbs, this compact and lightweight camera boasts powerful performance and versatility as it adapts to various demanding shooting scenarios. Like other Kinefinity cine cameras, MAVO Edge 6K brings natural color, pleasing skin tones, low noise, high dynamic range, and stunning details in an organic and delicate way.

Outstanding Highlight Performance with Stunning Image Quality
The MAVO Edge 6K is the latest full-frame camera from Kinefinity since the release of MAVO Edge 8K, and it employs a full-frame 3:2 CMOS imaging sensor that not only shows cleaner images but also provides wider viewing angles, shallower depth of field, and more immersive presence. The advanced color processing architecture from the MAVO Edge platform creates images with low noise, high latitude, and wide color gamut, then brings stunning details, organic images with exceptional quality. In addition, the full-frame 6K CMOS sensor is perfectly paired with OLPF FF3 optical low pass filter that adopts a more complex and higher performance crystal process to"eliminate" aliasing/artifacts while keeping very sharp images.

The MAVO Edge 6K is equipped with dual native ISO, rated at 800 and 5120, as the second native ISO up to 5120 is perfect for low light scenes to obtain a clean image with high latitude and low noise, ideal for documentary filmmakers or those who favor available light during night shoots.

MAVO Edge 6K outperforms its predecessor of MAVO LF a lot when it comes to highlight performance. At the industry standard ISO 800, the default highlight of the Edge 6K is 6.0 stops, capturing more highlight details to get a more cinematic look. Switch to Cine EI mode for more of a traditional cinema camera experience and highlight stops will adjust automatically as the EI changes. While using Cine EI mode, the second base native ISO 5120 is still activated when you go past 1600 EI.

Internal Motorized Full-Spectrum e-ND System
The MAVO Edge 6K employs an internal motorized full-spectrum e-ND system. The e-ND filter ranges from 0.6 to 2.4 which is a range from 2-8 stops neutral density and can be adjusted seamlessly over all the ranges, giving the user precise exposure control. The real-time color calibration on the e-ND filter brings sharp images with color fidelity but without any drawbacks of traditional variable ND.

  • Features:

    • Apple ProRes
    • Full Spectrum e-ND System
    • Dual SDI Outputs

  • Specifications:

    • CMOS Imaging Sensor & Filters
    • Imaging Sensor: 6K 3:2 Full Frame CMOS Imaging Sensor
    • Max Record Res: 6016x3984 (Open gate 3:2), 24M
    • Frame Rate: 0.2~75fps @FF 6K Wide, 0.2~150fps @S35 4K Wide
    • Active Area: 36x24mm, o 43.3mm
    • Dual Base ISO:
      - Regular Base ISO: 800 (from 500 - 2560)
      - High Base ISO: 5120 (from 3200 - 20480)
    • Latitude: >14 stops
    • Shutter Angle: 0.7°~358° with rolling shutter
    • Lens Mount: Omni Native KineMOUNT, Short FFD Adapters: PL/LPL/Active EF/passive E
    • Optical Filter: OLPF with UV and IR-cut filter
    • ND Filter: Built-in motorized: Clear and e-ND from 0.6 to 2.4

      Codecs/LUT
    • Record Codec:
      - Uncompressed RAW (dng/12 Bits)
      - ProRes4444XQ (Quicktime mov/12 Bits)
      - ProRes4444 (Quicktime mov/12 Bits)
      - ProRes422HQ (Quicktime mov/10 Bits) ProRes422/LT Included
    • LUT: KineLOG3, Neutral (Rec 709), Support Custom 3D LUT
    • Record Media: 2x Media Slot, for KineMAG Nano SSD 1TB based on NVMe M.2 SSD (3rd party NVMe M.2 2280 cards are also supported via the KineMAG Nano card body)
    • KineMAG Nano Size: 1.6" x 3.5" x 0.35" (40mm x 88mm x 9mm)(WxHxL)

      Monitoring
    • 2x Proprietary Video Port, for Kinefinity Viewfinder, KineMON-5U, KineMON-7U
    • 2x SDI 3G/1.5G with Meta data (regular BNC)

      Audio In and Out
    • Audio Sampling Spec: Linear PCM, 24bits, 48KHz
    • Audio Input:
      - Built-in Mono Microphone
      - 3.5mm Stereo MIC
      - 2x 48V Phantom Power Balanced Input (regular XLR)
    • Audio Output: 3.5mm Headphone Jack

      Wireless and Network
    • Wired: Gigabit Ethernet (RJ45 type) for live stream, camera control and data transfer
    • Wireless: WIFI 5 for live stream, camera control
    • Other: 3-axis accelerometer

      Sync and Control
    • Timecode: Linear TC In&Out (0B6P socket)
    • Control: Lens with RS232, Power output (0B6P)
    • Multi-sync, Control: SYNC with RS232 and Kinefinity camera sync (0B7P)
    • RS: Rec trigger input with Power output (fisher 3P)
    • Extension: Data & Control, EXT1 & EXT2(for pogo-pin, 2x4 contacts)
    • USB: 1x Type-C USB, can be used for firmware updates and importing custom LUTs

      Power In and Out
    • Power Consumption: 29W, when 6K 25p, liveview
    • Power Input:
      - DC Input (1B2P), 11~26V
      - Integrated V-mount battery plate, V-mount battery or BP-U compatible
      - UPS EXT 3 (for pogo-pin, 2x5 contacts)
    • Power Outputs:
      - 1x D-tap, Vbat @3A; Vbat as DC in or BAT in
      - 1x RS, Vbat @3A (Shared with D-Tap)
      - 1x Lens, Vbat @3A

      Construction and Size
    • Body Material: Ultra-high Strength Aircraft Aluminum
    • Body Weight: 3.5lbs (1.6kg)
    • Size (WxHxL): 4.1" x 4.8" x 4.3" (106mm x 124mm x 109mm)(w/o protrusion)
    • Operating Temp: 32°F - 104°F (0°C - 40°C)
    • Color: Deep Gray

  • Warranty:

    • 2 Year Warranty
