Kramer CA-USB31/CAE-10 USB-C 3.1 Gen 2 Male to USB Type-A-Female Active Extender Cable 10 Feet

Name: Kramer CA-USB31/CAE-10 USB-C 3.1 Gen 2 Male to USB Type-A-Female Active Extender Cable 10 Feet
Brand: Kramer
SKU: KR-CA-USB31CAE10
Price: 61.60 USD
Availability: PreSale

ITEM #: KR-CA-USB31CAE10 MFG #: CA-USB31/CAE-10

Kramer

List Price:

$77.00

Our Price:

$61.60

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

CA-USB31/CAE-10 - Overview

The Kramer CA-USB31/CAE-10 is an active extender cable designed to extend USB 3.1 GEN 2 (USB 3.2) signals. Typically, USB 3.1 GEN 2 cables have a maximum length of about 1 meter (3 feet), CA-USB31/CAE enables cable lengths of up to 4.7m (15ft). This bus-powered cable contains active electronics that enables it to extend without any signal loss or potential performance problems. With no need for an external power source, CA-USB31/CAE is suitable for use with USB cameras, printers, webcams, Soundbar, keyboards, mice, and more.

Note: This cable is for data transfer only, not for charging.

Features:
- Enables USB cable up to 4.7m (15ft).
- True Plug-and-Play - No additional drivers needed
- USB 3.1 Super Speed (10Gbps) Standard - Compliant with USB 3.0 and USB 2.0
- No External Power - Pulls power from the USB source device
- Buffers Incoming & Outgoing Signal
- CE & FCC certified
Specifications:
- General
- Type: USB 3.1 GEN 2 SuperSpeed Plus
- Max Data Rate: 10 Gbps

  Physical
- Connector A: USB 3.1 GEN 2 type-C mal
- Connector B: USB 3.1 GEN 2 type-A female

  Mechanical
- Cable Bending Radius: 50mm(min)

  Conductors
- Cable Composition: 30AWG{7/0.103TC)+EAM]*2P+[30AWG{7/0.10TC)+A]*1P+24AWG(41/0.08TC)*1C+2EB(16/11/0.08TC)

  Jacket
- Material: TPE
- O.D.: 4.8mm
- Color: Black

  Power
- Power Consumption: =1W
- Power Consumption: Power delivery:900mA (4.5W)
- Power delivery: 900mA (4.5W)
