Link Electronics IPC-92 Ethernet to Serial Converter IP Caption Connection

ITEM #: LEI-IPC-92 MFG #: IPC-92

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$450.00

Our Price:

$428.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


IPC-92 - Overview

The IPC-92 is an Ethernet to serial converter that can be used for Internet Protocol address (IP) captioning. The unit is pre-setup at the factory to work with Link encoders. All setup is controlled through a web page that is stored in the device so no software installation is required, if for some reason you need to change the settings you just use any popular web browser. Using the IPC-92 means that a data phone line is no longer needed for captioning. Program audio will still have to be sent to the captioner via phone line, Skype, voice over IP, web streaming, or the list goes on.

  • Features:

    • Ethernet to serial
    • IP Captioning
    • No software
    • Pre-setup for Link Encoders
    • Customizable Setup
    • No Caption Data Phone Line
    • No Caption Server Fees
    • Web Interface

  • Specifications:

    • Serial DE-9 (DB9) Male Connector
    • Protection: ±15kV ESD on Rx Inputs and Tx Outputs
    • Baud: 300 bps to 240K bps (1200 Default)
    • Characters: 7 or 8 Bits (8 Default)
    • Parity: Odd, Even or None (None Default)
    • Stop Bits: 1 or 2 bits (1 Default)
      Ethernet RJ45 Connector
    • Interface: Ethernet 10Base-T or 100Base-TX (Auto-Sensing)
    • Protocols: TCP/IP, UDP/IP, Telnet, DHCP, and Auto IP
    • Indicators: 10Base-T/100Base-TX connection and Link/Activity
      Power
    • External Power Supply: 5VDC Regulated Positive Center Pin
    • Power: 2A
    • Indicator: Green LED
      Environment
    • Ambient: 0° C to 40° C
    • Relative Humidity: <95% non-condensing
      Mechanical
    • Height: 1.4 Inch
    • Width: 4.5 Inch
    • Length: 2.6 Inch
    • Weight: 5.5 oz.


IPC-92 - Required Accessories
