Lilliput 663 S2 7 Inch 3G-SDI Monitor

ITEM #: LIL-663-S2 MFG #: 663/S2

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$459.00

Our Price:

$439.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


663/S2 - Overview

See clearly with the Lilliput 663/S2! Lilliput 663/S2 7 inch 3G SDI in and out Monitor with Waveform Function

The Lilliput 663/S2 is a 7 inch , metal framed 3G SDI Monitor with Waveform Function. This 16:9 LED Backlit Field Monitor is compact in size but boasts a high 1280x800 resolution, 800:1 contrast ratio and 178 degree viewing angle providing detailed images, rich, accurate color! Full control with onboard functions like Waveform, Vector Scope, Peaking, Histogram and Exposure, there's even a video analyzer and audio level meter. The Lilliput 663/S2 has an HDMI monitoring output, no splitters needed, and inputs like HDMI, 3G-SDI, component and composite. Built in user friendly features like 4 programmable front panel shortcut buttons, a speaker, headphone jack and a screen protector that folds out into a sun hood. All this and it's still small enough to easily fit into your camera bag!

  • Features:

    • High resolution: 800x480
    • High brightness: 450cd/m/2
    • High contrast: 500:1
    • DV battery plates for power
    • Multi mounts methods & angles
    • Wide voltage: 6-24V
    • 3G-SDI input

  • Specifications:

    • Display
    • Panel: 7 INCH LED backlit
    • Physical Resolution: 800 x 480, supports up to 1920 x 1080
    • Aspect Ratio: 16:9
    • Brightness: 450cd/M2
    • Contrast: 500:1
    • Viewing Angle: 140°/120°(H/V)

      Input
    • 3G-SDI: 1
    • HDMI: 1
    • YPbPr: 3 (BNC)
    • Video: 2
    • Audio: 1

      Output
    • 3G-SDI: 1

      Audio
    • Speaker: 1
    • Audio Output: 1W

      Power
    • Current: 650mA
    • Input Voltage: DC 6-24V(XLR)
    • Battery Plate: F970/QM91D/DU21/LP-E6
    • Power Consumption: 8W

  • Item Includes:

    • Lilliput 663/S2 7 inch 3G-SDI Field LED Monitor
    • Metal Carry Case
    • Remote Control
    • 568 Bracket
    • Shoe Mount
    • HDMI A Cable
    • F-970 Type Battery Plate
    • LP-E6 Type Battery Plate
    • Sun Shade/Screen Protector
    • DC Adapter
    • Lilliput 1 Year Limited Warranty

  • GTIN:

    6950821600801
