Lake People G103-D4 Dante Headphone Amplifier with a DANTE 4/4 Input and Two Independent Stereo Amplifiers

ITEM #: LP-G103-D4 MFG #: G103-D4

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Lake People USA
Free Shipping with $49 Minimum Order

Our Price:

$699.00

Add to Wish ListLeasing Options
Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    G103-D4 - Overview

    Lake People's G103-D is a headphone amplifier intended for Dante networks. The G103-D4 model comes with a Dante 4/4 input and two independent stereo amplifiers. 24 Bit/192 kHz D/A converters with a Signal-to-noise ratio of >105 dB and THD+N as low as 0.002% are driving the powerful headphone amplifiers. These are best suited to drive any headphones from low to high impedance and with low or high sensitivity. To adapt the amp to demanding headphones, to further reduce the noise level or to maximize the travel of the volume control, the gain is internally adaptable by Dip-Switches to optimize the amp.

    • Features:

      • 4/4 Dante network input via RJ45
      • 24 Bit D/A converter with SNR > 105 dB
      • Alps volume control with good channel balance and low crosstalk
      • powerful amplifiers
      • 3 internal gains switchable
      • 1/4" and 3.5mm headphone connectors
      • Flexible power supply covering PoE, USB-B, -C


    • Specifications:

      • Input: Dante digital audio
      • Connector: RJ45
      • Channels: 4 (2x Stereo)
      • D/A Converter: 24-bit (up to 192 kHz)
      • Analog Level: +9 dB for 0 dBFs
      • Additional Gain: +6/+12 dB, int. selectable
      • Frequency Range: 5 - 90 kHz (-0.5 dB)
      • Dynamic Range: > 105 dB (A-weighted)
      • THD+N: < 0.01% (500mW/100R)
      • Crosstalk: > -80 dB (@15 kHz)
      • Output Impedance: < 1 Ω
      • Damping Factor: 50 (load 50 Ω)
      • Max. Output Level:
        > 9.5 Veff in 600 Ω = 115 mW
        > 8.1 Veff in 300 Ω = 220 mW
        > 7.1 Veff in 100 Ω = 500 mW
        > 6.1 Veff in 50 Ω = 750 mW
        > 5.2 Veff in 32 Ω = 830 mW
        > 2.7 Veff in 16 Ω = 440 mW
      • Outputs:
        - 1x 1/4"
        - 1x 3.5mm phone jacks
      • Power Supply: PoE/USB-B. -C (5V max. 10 VA)
      • Case Dimensions: 4.13" x 1.65" x 6.5" (105mm x 42mm x 165mm)
      • Front Panel: 4.25" x 1.77" (108mm x 45mm)
      • Case Material: Black anodized aluminum


    • Item Includes:

      • 1x Lake People G103D4
      • 1x Manual


    • Warranty:

      • 2 years
