Litepanels Gemini 2x1 LED Soft Panel with Yoke and US powerCon Connection

ITEM #: LPAN-940-1301 MFG #: 940-1301

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$3,500.00

Our Price:

$3,325.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


940-1301 - Overview

The industry's most accurate and versatile 2x1 soft panel

The Litepanels Gemini is a 2x1 LED panel that provides a wide soft source of color accurate illumination. The Gemini has accurate full spectrum Daylight and Tungsten lighting and now features a new Lighting Effects Mode!

With Lighting Effects Mode you control rate, color, depth and more to create a unique customized look. Effects pre-sets allow you to save and recall your effects and they can also be copied to a USB drive for importing to other lights. The fully customizable effects are TV Simulation, Fire, Emergency Lights, Strobe, Pulse, Fireworks, Party Lights, Paparazzi, Hue Burst and Squares!

The Gemini also allows for additional quick and easy adjustment by offering three full featured lighting modes:

1. CCT (Correlated Color Temperature) Mode allows for Bi-Color (Daylight to Tungsten) operation with the addition of plus and minus Green offset
2. HSI Color Mode allows for full color control over Hue, Saturation and Intensity
3. Gel Mode allows for a variety of Gels to be selected from the menu

There is also full color with hue and saturation control, all of which allow for the intensity to be controlled anywhere from 100%-0 at all times.
The Gemini is truly versatile with its manual and remote control via standard DMX 512 protocol or wirelessly with the option of wireless DMX or Bluetooth; fully adaptable to any lighting situation today's Cinematographers and lighting professionals will find themselves in.

The manual control knobs are sensitive to the speed of rotation and can either be finely tuned or when ramped up, they can adjust very quickly. With its lightweight design, the Gemini allows for additional versatility with mobile power operation via 3pin XLR, making it a perfect location light.

  • Features:

    • Flexible, modular concept
    • No heavy external ballast or restrike period
    • Flicker-free at any frame rate or shutter angle at any intensity level
    • AC/DC power with DC power via 3-pin XLR
    • Ultra-smooth dimming from 100% to 0, with no color shift
    • Master Slave mode - connect multiple lights together and control them all together from one light as the master control
    • Optional Bluetooth and wireless DMX modules allow the brightness, color and cooling mode to be remote controlled
    • Modern fixture design with integrated power supply
    • Intuitive and ergonomic controls for dimming, color and fixture set up
    • Aluminum core construction to provide maximum durability and superior thermal management
    • Barndoor/honeycomb accessory rails
    • Durable, industry standard PowerCon locking power connector with ability to daisy chain power
    • Ability to stack and gang lights together with optional hardware and yoke
    • LCD screen displays vital setting and status
    • Six defined CCT presets plus six user programmers presets
    • The Gemini allows for the user presets on Channel A which records color and intensity it also has factory presets on channel "B" with increments for 2700K to 6000K

  • Specifications:

    • Beam angle: 93°
    • Max. power draw: 325W
    • Optics: Medium diffusion panel
    • Weight: 22lbs
    • Power supply: 28VDC / 100-240VAC
    • Dimensions: 25 x 6.5 x 12.5"
    • CRI: 97/99
    • Wireless: Wireless DMX and Bluetooth
    • Gel filters/Diffusers: Gel mode with option of Daylight ot Tungsten source
    • Fixture type: Panel lights
    • Color temperature: Tungsten-Daylight

  • Item Includes:

    • Gemini Fixture with integrated power supply
    • Mounting yoke with Jr Pin
    • 3m powerCON cable

  • GTIN:

    0859058005303
