Middle Atlantic SNE30D-4542-P1 SNE Series 45RU Digital IP Security Systems Rack - 30 Inch Width - 42 Inch Depth

SNE30D-4542-P1 - Overview

• Features:

  • Fully configured Security Network Enclosure with passive ventilation for data centers
  • 70% open area vented front door
  • Pair of split flush mount locking side panels
  • Pair of split flush mount locking side panels o 2 pair of adjustable cage-nut rackrail (including 6mm hardware)
  • 30" width / 42" overall depth
  • 45 rackspace o 100 6mm cage-nuts/rack screws included SNE Series Digital with passive cooling (front to rear)
  • Lever Lock™ compatible (accepts all 21" vertical accessories)
  • Configured for passive front-to-back cooling
  • Includes 70% open front door and 70% open area split rear door
  • UL/ETL listed and seismic certified


• Specifications:

  • Airflow Direction: Passive Front to Rear
  • Component Type: Passive
  • Federal Ops Country of Origin: USA
  • Finish: Black Texture Powder Coat
  • Gangable: Yes
  • Material: Steel
  • Product Configuration: Pre-Configured
  • Rack Rail Type: Cage Nut
  • Rack Type: Pre-Configured
  • Rear Door: Yes
  • Seismic Rated: Yes
  • Side Panel: Yes
  • System Type: Digital
  • Depth: 42 in (106.7 cm)
  • Height: 84.77 in (215.3 cm)
  • Panel Width: 19 in (48.3 cm)
  • Rack Units: 45 RU
  • UL Load Capacity: 3000 lbs (1,360.8 kg)
  • Usable Depth: 38.48 in (97.7 cm)
  • Usable Height: 78.75 in (200 cm)
  • Width: 30 in (76.2 cm)
  • Certifications: TAA, UL Listed
  • Seismic Load Capacity: 1050 lbs (476.3 kg)


• Item Includes:

  • 1x Solid top with brush cable pass-through
  • 2x Pair of split flush mount locking side panels
  • 2x Pair of adjustable cage-nut rackrail
  • 1x 100 6mm cage nuts and rack screws
  • 4x Leveling feet
  • 4x Casters
