Mackie DLM12 2000W 12 Inch Powered Loudspeaker

ITEM #: MCK-DLM12 MFG #: DLM12

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

Our Price:

$999.99

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


DLM12 - Overview

The Mackie DLM12 powered loudspeaker delivers 2000W into the most compact, professional and portable loudspeaker design ever. Featuring TruSource™ technology, the DLM loudspeakers are equipped with Mackie's TruSource driver that incorporates the high-output 12" woofer and 1.75" compression driver into an incredibly compact common-magnet design. Powerful TruSource DSP delivers seamless clarity, consistent dispersion and unmatched fidelity.

This versatile loudspeaker features the Mackie DL2 integrated digital mixer, providing a dual-channel mixing solution for a wide array of possible connections with incredible channel features like 3-band EQ and 16 great-sounding effects. Plus, system processing like a multi-band feedback destroyer, six speaker modes and Smart Protect technology provide the tools needed for truly professional applications.

With configuration options that include pole/wall mounting and flying, the sleek DLM loudspeakers are a powerful solution for high-end installs. the ultra-compact form factor includes a rugged PC-ABS cabinet, powder-coated grille and integrated kickstand for personal monitor use.

The new shape of sound - the Mackie DLM12!!

Innovative Compact Design
Incredibly powerful, Mackie DLM Series loudspeakers deliver premium sound in the most compact, professional portable loudspeaker series ever. Perfect for bands, venues and installs, the powerful, compact DLM series is the new shape of sound.

The New Shape Of Sound
Featuring Mackie's TruSource™ vertically-aligned, common-magnet driver and TruSource DSP for unmatched fidelity and packed with cutting-edge technology to deliver a staggering 2000 watts of power in a groundbreaking design with an integrated digital mixer plus all the channel effects and system processing you've ever wanted.

  • Features:

    • 2000W system power via ulta-efficient Class-D amplification
    • TruSource™ technology
    • DL2 Integrated Digital Mixer
    • 2 highly-versatile input channels with FX
    • Independent channel level, 3-band EQ and effects control
    • 16 great-sounding effects include, reverb, chorus and delay
    • XLR/TRS combo and dual RCA connectors
    • Handles mic, line, stereo and instrument signals
    • Multi-band feedback destroyer
    • 6 speaker modes deliver the perfect voicing for your application
    • 3 memory locations for instant venue setting recall
    • Innovative ultra-compact design to where you can fit an entire DLM system in nearly any car and are stackable for easy storage
    • Pole-mountable on tripod or atop a DLM12S using a SPM300 speaker pole
    • Flyable via standard M10 rigging hardware
    • Wall-mount them using the SWM300 articulated arm for stealthy, powerful install system
    • Integrated kickstand delivers the perfect angle for personal monitor use

      **NOTE** Floor mount, pole mount, wall mount or fly via 3 integrated M10 mounting points (using M10 x 17mm forged shoulder eyebolts).

  • Specifications:

    • Acoustic Performance
    • Frequency Response (-10dB): 38Hz - 20kHz
    • Max peak SPL: 128dB
    • Crossover Point: 1.6kHz
    • Dispersion: 90° conical

      Equalization
    • Low Shelving: ±15dB @ 80Hz
    • Mid-Peaking: ±15dB @ 2.5kHz
    • High Shelving: ±15dB @ 12kHz
    • Increments: ±3dB

      High-Frequency Section
    • Voice Coil Diameter: 1.75"
    • Horn Entry Diameter: 1"
    • Diaphragm Material: Polyimide Film
    • Magnet Material: Ferrite

      Low-Frequency Section
    • Woofer Diameter: 12"
    • Voice Coil Diameter: 2.5"
    • Diaphragm Material: Paper
    • Magnet Material: Ferrite

      Power Amplifier
    • System Rated Power: 1000W RMS, 2000W peak
    • HI/LO Freq. Rated Power: 500W RMS, 1000W Peak
    • HI/LO Freq. Rated THD: <1%
    • HI/LO Freq. Cooling: Multi-speed fan
    • HI/LO Freq. Design: Class D

      DL2 Digital System Processing
    • EQ: 6 speaker modes
    • Alignment Delay: 0 - 300ms
    • FX: 16 presets
    • Multi-band Feedback Destroyer: ON/OFF/CLEAR/HOLD
    • Memory: 3 locations for instant venue setting recall and facrtory reset

      Channel 1 Input/Output
    • Mic: 3.3kΩ balanced
    • Line: 20kΩ balanced, 10kΩ unbalanced
    • 1/4" TRS: 16kΩ balanced, 8kΩ unbalanced

      Channel 2 Input/Output
    • XLR Line: 20kΩ balanced, 10kΩ unbalanced
    • 1/4" TRS (HI-Z Instrument): 1MΩ unbalanced
    • RCA: 25Ω unbalanced
    • Thru: Male XLR balanced

      Power
    • Detachable Line Cord: 100 - 120V AC, 50 - 60Hz, 250W
    • AC Connector: 3-pin IEC 250V AC
    • Operating Temperature: 32°F - 104°F

      Safety Features
    • Input Protection: Peak and RMS limiting, power supply and amplifier thermal protection
    • Display LEDs: Defeatable front power ON, Front load power limiter
    • Status Info: Power supply voltage, Core temperature

      Construction Features
    • Cabinet: PC-ABS (High-strength)
    • Finish: High durability black paint
    • Handles: One on top
    • Grille: Powder-coated 20 gauge steel
    • Fly Points: 3 M10 x 17mm
    • Monitor Angle: 50° (using integrated kickstand)

      Physical
    • Dimensions (HxWxD): 15.9" x 15.3" x 14.3"
    • Weight: 31lbs

  • Warranty:

    • 3-year inclusive of electronics, 2-year drivers (where applicable), nontransferable

  • GTIN:

    0663961036282
