MOTU Micro Express 4-in/6-out MIDI Interface with SMPTE Synchronization

ITEM #: MOTU-MICROEX MFG #: MICRO EXPRESS US

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$295.00

Our Price:

$249.00

Availability: 2+ Weeks.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


MICRO EXPRESS US - Overview

The micro express is a mini version of the MIDI Express XT. It has many of the same features as the Express XT - except that it is smaller and even more affordable. The micro express is a half-rack unit with 4 inputs and 6 outputs. The micro express takes full advantage of USB, giving you increased MIDI throughput, better timing accuracy, support for "hot-swapping" and plug-and-play expansion. Need to connect another sound module or synth? No problem. Just add another MOTU USB MIDI interface via a standard USB hub.

  • Features:

    • MIDI interface for Macintosh and Windows
    • Can connect both a Mac and a PC at the same time
    • Standalone MIDI patchbay/merger/processor
    • SMPTE tape sync in all formats
    • 4 x 6 MIDI merge matrix - connects any device to any other
    • Front panel presets for plug-and-play convenience
    • 4 independent MIDI IN
    • 6 independent MIDI OUT (9 actual MIDI OUT ports)
    • 96 MIDI channels
    • Supports MIDI Machine Control transport messages
    • Pedal input for momentary foot switch
    • Audio click input - converts audio click into MIDI data
    • 16 presets with 8 programmable, battery-backed memories
    • Recalls setups via MIDI patch change
    • Includes software for Macintosh and Windows

    • Internal power supply
      MIDI processing:
    • Merge any inputs to any outputs
    • Route any inputs to any outputs
    • Mute any MIDI data on any cable
    • Re-channelize on input and output
      Synchronization:
    • SMPTE time code (LTC) generator and reader
    • Converts LTC to MIDI Time Code (MTC) to sync a Mac, PC or any other devices to SMPTE time code
    • Converts all SMPTE frame rates (24, 25, 29.97 drop, 29.97 non-drop, 30)
    • Stripes SMPTE time code in all frame rates (24, 25, 29.97 drop, 29.97 non-drop, 30)
    • Converts MIDI Time Code to SMPTE time code
    • SMPTE "Jam Sync" with adjustable freewheeling for dropout-free sync
    • Supports MIDI Machine Control - serves as either an MMC master or slave, distributes MMC transport commands to all other MMC devices

  • GTIN:

    0839128005136
