NTI UNIMUX-DP4K-2DH 2-Port Dual Monitor 4K DisplayPort USB KVM Switch with Built-In USB 3.2 Hub

UNIMUX-DP4K-2DH - Overview

• Features:

  • Dual Head
  • Resolutions to Ultra-HD 4Kx2K 60Hz 4:4:4
  • 21.6 Gbps
  • DisplayPort 1.2, USB 3.2


• Specifications:

  • Hosts
  • Four female DisplayPort connectors.
  • Two Female USB 3.2 Type B connectors.
  • Supports dual-head USB-enabled computers (PC and MAC) with DisplayPort video.
  • Multiplatform support: Windows 7/8/8.1/10, Mac OS 9/10.
  • Compliant with DisplayPort 1.2 and HDCP standards.

    Monitor
  • Supports Ultra-HD 4Kx2K resolutions to 3840x2160 @60Hz YCbCr 4:4:4, and HDTV resolutions to 1080p @144Hz.
  • Two female DisplayPort connectors.
  • Compliant with DisplayPort 1.2 and HDCP standards.

    Devices
  • Four transparent USB 3.2 ports for connecting USB devices such as keyboards, mice, printers, game controllers, USB flash drives, touch screen monitors, whiteboards, etc.
  • Supports SuperSpeed (5 Gbps), high-speed (480 Mbps), fullspeed (12 Mbps), or low-speed (1.5 Mbps) USB devices.
  • Backwards compatible with USB 2.0/1.1.

    Power
  • Input: 110 or 220 VAC at 50 or 60 Hz via AC adapter (included).
  • Output: 5VDC, 4A
  • Power consumption: 6.5W
  • Each USB output port supports full 900mA current.

    Dimensions
  • WxDxH: 8.27x2.36x1.4 in (210x60x35.6 mm)

    Cables
  • Interface cables between the computers and the switch are required for proper operation.
  • Use DP-xx-MM cable to connect a DisplayPort source or display up to 15 feet.
  • Use DP8K-FO-xxM-MMLC or DP4K21GB-FO-xxM-MM to connect a DisplayPort source or display up to 100 meters.
  • Use DP-HD-xx-MM to connect an HDMI display up to 15 feet. Not compatible with MAC.
  • Use DP-DVI-xx-MM to connect a DVI display up to 15 feet. Not compatible with MAC.
  • Use DP-VGA-xx-MM to connect a VGA display up to 15 feet. Not compatible with MAC.
  • Use USB3-AB-xx-L to connect a USB 3.0 computer to the switch. Cables not included.

    Environmental
  • Operating temperature: 32 to 158°F (0 to 70°C).
  • Regulatory Approval: CE, FCC, RoHS, TAA compliant


• Warranty:

  • 2 Years
