Neumann TLM193 Transformer Less Condenser Microphone

ITEM #: NEUM-TLM193 MFG #: TLM193

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$1,999.00

Our Price:

$1,595.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


TLM193 - Overview

A large-diaphragm mic reduced to the essentials, but with no compromise in quality, featuring a cardioid directional characteristic and a classic design.

The TLM 193 is a large diaphragm microphone with a cardioid polar pattern. With this microphone Neumann continues its long tradition, and is offering high end technology at an affordable price for musicians and the home recording studio.

The microphone uses a transformerless circuit, featuring extremely low self noise and large dynamic range.

The polar response is very linear over a wide incidence angle. Thus, even signals coming from the side are reproduced faithfully and without coloration. The exposed surface of the microphone capsule is at ground potential, making it immune to typical interference and contamination. The microphone is supplied with a swivel mount.

  • Features:

    • Large diaphragm cardioid microphone
    • Pressure-gradient transducer
    • Transformerless circuitry
    • Extremely low noise: 10 dB (A)
    • Includes swivel mount
    • The "plug and play" microphone for professional studios, musicians and homerecording applications
    • High-quality professional equipment for mid-size budgets

  • Specifications:

    • Acoustical operating principle Pressure gradient transducer
    • Directional pattern Cardioid
    • Frequency range 20 Hz ... 20 kHz
    • Sensitivity at 1 kHz into 1 kohms 18 mV/Pa
    • Rated impedance 50 ohms
    • Rated load impedance 1 kohms
    • Equivalent noise level, CCIR1) 21 dB
    • Equivalent noise level, A-weighted1) 10 dB-A
    • Signal-to-noise ratio, CCIR1) (rel. 94 dB SPL) 73 dB
    • Signal-to-noise ratio, A-weighted1) (rel. 94 dB SPL) 84 dB
    • Maximum SPL for THD 0.5%2) 140 dB
    • Maximum output voltage 13 dBu
    • Dynamic range of the microphone amplifier (A-weighted) 130 dB
    • Supply voltage (P48, IEC 61938) 48 V ± 4 V
    • Current consumption (P48, IEC 61938) 3 mA
    • Matching connectors XLR3F
    • Weight 480 g
    • Diameter 49 mm
    • Length 175 mm
      1) according to IEC 60268-1; CCIR-weighting acccording to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS
    • 2) measured as equivalent el. input signal

  • GTIN:

    0615104083813
