Tripp Lite Omni900LCD Digital UPS with LCD Display

Name: Tripp Lite Omni900LCD Digital UPS with LCD Display
Brand: Tripp Lite
SKU: OMNI900LCD
Price: 180.00 USD
Availability: PreSale

ITEM #: OMNI900LCD MFG #: OMNI900LCD

Tripp Lite

List Price:

$292.04

Our Price:

$180.00

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

OMNI900LCD - Overview

Tripp Lite's OMNI900LCD Line-Interactive Digital UPS System offers voltage regulation, surge suppression and long lasting battery support for personal computers, home entertainment systems and media centers. Internal UPS circuits support entry level PCs for up to 50 minutes or individual VCR/DVR components for as long as 2.5 hours during power failures. Prevents data loss, viewing interruptions, lost recordings and loss of component programming. Automatic Voltage Regulation (AVR) circuits regulate brownouts as low as 89 volts back to usable levels without using battery power. 97% line-mode efficiency saves energy and reduces BTU heat output. Offers complete power protection in an attractive black tower configuration. Includes 4 battery-supported and surge-protected outlets, plus 4 additional surge suppression-only outlets for items not requiring battery support. USB port enables optional unattended system shutdown without data loss in the case of extended power failure. PowerAlert software available via free download. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Built-in audible alarm and large LCD front panel voltage display indicates line power status, battery power status, battery low/replace status and voltage boost operation. The LCD display includes a dimmer switch and can be rotated for easy viewing in any application. 900VA/475 watt power handling ability supports entry-level PCs, home entertainment systems, network workstations, audio/video components. Offers 3 minutes battery runtime with a full load of 900VA/475 watts and 10 minutes with a half load of 450VA/237 watts.

Features:
- LCD Display indicates input voltage, battery capacity and a variety of operating conditions. Display is rotatable for easy viewing whether UPS is in vertical or horizontal position
- OMNI900LCD Digital Uninterruptible Power Supply offers voltage regulation, surge suppression and long lasting battery support during blackouts
- Supports entry level PCs up to 50 minutes or single VCR/DVR components for up to 2.5 hours during blackouts
- Regulates brownouts as low as 89 volts back to usable levels without using battery power
Specifications:
- Output
- Output Volt Amp Capacity (VA): 900
- Output Watt Capacity (Watts): 475
- Nominal Voltage Details: 115v nominal output in battery mode
- Frequency Compatibility: 60 Hz
- Output Voltage Regulation (Battery Mode): +/- 5%
- UPS Output Receptacles (Surge Suppression Only): 4 UPS outlets, 4 surge-only outlets
- Hot-Swap PDU options: PDUB15 (2U / 8 5-15R outlets)
- Output AC Waveform (AC Mode): Sine wave
- Output AC Waveform (Battery Mode): PWM sine wave
- Nominal Output Voltage(s) Supported: 110V; 115V; 120V
- Output Receptacles: (8) 5-15R
- Individually Controllable Load Banks: No

  Input
- Rated input current (Maximum Load): 12A
- Nominal Input Voltage(s) Supported: 120V AC
- UPS Input Connection Type: 5-15P; Right-Angled
- UPS Input Cord Length (ft.): 6
- Recommended Electrical Service: 15A 120V
- Input Phase: Single-Phase

  Battery
- Full Load Runtime (min.): 3 min. (475w)
- Half Load Runtime (min.): 10 min. (240w)
- DC System Voltage (VDC): 12
- Battery Recharge Rate (Included Batteries): Less than 16 hours from 10% to 90%
- Internal UPS Replacement Battery Cartridge: RBC51
- Battery Access: Battery access door
- Battery Replacement Description: Hot-swappable, user replaceable batteries
- Expandable Runtime: No

  Voltage Regulation
- Voltage Regulation Description: Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89
- Undervoltage Correction: Input voltages between 89 and 104 are boosted by 14%

  User Interface, Alerts & Controls
- Front Panel LCD Display: Backlighted LCD screen indicates input voltage, 5-bar battery charge level, overload, AVR, on battery and replace battery status; LCD screen rotates for rack/tower viewing
- Switches: 2 Switches control off/on power status and alarm-cancel/self-test operation; dimmer switch controls LCD brightness
- Alarm Cancel Operation: Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status
- Audible Alarm: Audible alarm indicates power-failure and low-battery status; alarm can be disabled using PowerAlert software
- LED Indicators: Front panel LCD display

  Surge / Noise Suppression
- UPS AC Suppression Joule Rating: 870
- UPS AC Suppression Response Time: Instantaneous
- EMI / RFI AC Noise Suppression: Yes

  Physical
- Installation Form Factors Supported with Included Accessories: Tower
- Primary Form Factor: Tower
- Primary UPS Depth (mm): 183
- Primary UPS Height (mm): 300
- Primary UPS Width (mm): 94
- Shipping Dimensions (hwd / in.): 15.50 x 4.70 x 10.50
- Shipping Weight (lbs.): 16.50
- UPS Housing Material: ABS
- UPS Power Module Dimensions (hwd, in.): 11.8 x 3.7 x 7.2
- UPS Power Module Weight (kg): 6.85
- UPS Power Module Weight (lbs.): 15.1

  Environmental
- Operating Temperature Range: +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- Storage Temperature Range: +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
- Relative Humidity: 0 to 95%, non-condensing
- AC Mode BTU / Hr. (Full Load): 61
- Battery Mode BTU / Hr. (Full Load): 485
- AC Mode Efficiency Rating (100% Load): 97%

  Communications
- PowerAlert Software: For local monitoring via the UPS's built-in USB port
- Communications Cable: User supplies USB cable
- WatchDog Compatibility: Supports Watchdog application, OS and hard-reboot restart options for remote applications
- Network UPS Tools Compatibility: NUT compatible.
- Communications Interface: USB (HID enabled)

  Line / Battery Transfer
- Transfer Time: 4 milliseconds (AC to Battery); 3 milliseconds (Battery to AC)
- Low Voltage Transfer to Battery Power (Setpoint): 89
- High Voltage Transfer to Battery Power (Setpoint): 139

  Special Features
- Cold Start (Startup in Battery Mode During a Power Failure): Cold-start operation supported
- Green Energy-Saving Features: Greater than 95% efficiency - GREEN UPS
GTIN:
0037332125156

OMNI900LCD - Recommended Accessories

Klein Tools ET310 Digital Circuit Breaker Finder
KLT-ET310
Our Price: $54.97
Dataprobe iBoot-G2S 2 Port 10/100 Network Power Switch - Web Power Switch
DTPB-IBOOT-G2S
Our Price: $279.00

OMNI900LCD - Reviews

OMNI900LCD - Attachments

See Tripplite OMNI900LCDSpecifications (PDF)
