Panasonic PT-RZ790BU 7200-Lumen WUXGA DLP Projector - Black

ITEM #: PAN-PT-RZ790BU MFG #: PT-RZ790BU

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Panasonic
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$17,649.00

Our Price:

$8,938.00

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

PT-RZ790BU - Overview

Deepen immersion in any environment with vivid, accurate colors backed by up to 910,0400 lm of brightness thanks to Quartet Color Harmonizer and 1-Chip DLP™ imaging technology. With support for 4K/60p input signals, separate DIGITAL LINK and LAN terminals, and diverse optional lenses, these projectors reduce installation hassles with convenient flexibility.Engineered for 20,000 hours of maintenance-free reliability with lasting brightness and color uniformity from the industry's leading dust-resistant optical engine.

Power to Impress with Accurate Colors
Deepen immersion in any environment with high brightness, rich color, and accurate white balance thanks to Quartet Color Harmonizer and 1-Chip DLP™ imaging technology

Easy to Install and Integrate
With versatile apps and functions, diverse optional lenses, support for 4K input signals*1, and separate DIGITAL LINK and LAN terminals, these projectors reduce installation hassles with convenient flexibility.

Reliable Even in Harsh Conditions
Engineered for 20,000 hours of maintenance-free reliability with lasting brightness and color uniformity from the industry's leading
dust-resistant optical engine.

  • Features:

    • System Daylight View 3 and Detail Clarity Processor
    • Dynamic Contrast Sync and Shutter Sync functions
    • Multi-Unit Brightness and Color Control
    • Supports Crestron, AMX, and Extron control
    • Quick Start and Quick Off
    • Geometry Manager Pro Software with optional expansion kits
    • Multi Monitoring & Control Software with optional Early Warning Functions


  • Specifications:

    • Projector Type: 1-Chip DLP™ projector
    • DLP™ Chip | Panel Size: 17.0 mm (0.67 in) diagonal ( Panel size 16:10 aspect ratio)
    • DLP™ Chip | Display Method: DLP™ chip x 1, DLP™ projection system
    • DLP™ chip | Number of Pixels: 2,304,000 (1920 x 1200 pixels)
    • Light Source: Laser diodes
    • Light output: 7,000 lm (Normal)*1 /7,200 lm (Center)*2 / 5,600 lm (Eco)*1 /2,800 lm (Long Life 1)*1 / 2,300 lm (Long Life 2)*1 /1,900 lm (Long Life 3)*1
    • Time until light output declines to 50 %*3: 20,000 hours (Normal)/24,000 hours (Eco)
    • Resolution: 1920 x 1200 pixels
    • Contrast Ratio*1: 10,000:1 (Full On/Full Off, Dynamic Contrast [3] )
    • Screen size [diagonal]: 1.27-15.24 m (50-600 in), 1.27-5.08 m (50-200 in) with ET-DLE055, 2.54-8.89 m (100-350 in) with
      ET-DLE035, 2.54-10.16 m (100-400 in) with ET-DLE020, 16:10 aspect ratio
    • Center-to-corner zone ratio*1: 90 %
    • Lens: With supplied lens: Powered zoom (throw ratio 1.71-2.41:1), powered focus F 1.7-1.9, f 25.6-35.7 mm Without lens:
      Optional powered zoom/focus lenses
    • Lens shift*4 | Vertical(From the origin point of the lens mounter): +50 %, -16 % (+40 %, -16 % with ET-DLE060) (powered)
    • Lens shift*4 | Horizontal(From the origin point of the lens mounter): +30 %, -10 % (+10 %, -20 % with ET-DLE020, +19 %,
      -10 % with ET-DLE060, +28 %, -10 % with ET-DLE105/ET-DLE085) (powered)
    • Keystone Correction Range: Vertical: ±40 ° (±5 ° with ET-DLE020, ±16 ° with ET-DLE060, ±22 ° with
      ET-DLE105/ET-DLE085/ET-DLE055, +5 ° with ET-DLE035), Horizontal: ±15 ° (±10 ° with ET-DLE060) (cannot be operated with ET-DLE035/ET-DLE020)
    • Keystone correction range with optional ET-UK20 Upgrade Kit: Vertical: ±45 ° (±16 ° with ET-DLE060, ±40 ° with ET-DLE150/ET-DLE250/ET-DLE170, ±22 ° with ET-DLE105/ET-DLE085/ET-DLE055), Horizontal: ±40 ° (±10 ° with ET-DLE060, ±15 ° with ET-DLE105/ET-DLE085/ET-DLE055) When [VERTICAL KEYSTONE] and [HORIZONTAL KEYSTONE] are used simultaneously, correction cannot be made
      exceeding a total of 55 °.
    • Terminals | SDI In: BNC x 1: 3G/HD/SD-SDI input
    • Terminals | HDMI In: HDMI 19-pin x 1 (Compatible with HDCP 2.2, Deep Color, 4K/60p signal input*5 )
    • Terminals | DVI-D In: DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
    • Terminals | RGB 1 In: RGB x 1 (BNC x 5): RGB/YPBPR/YCBCR
    • Terminals | RGB 2 In: D-sub HD 15-pin (female) x 1: RGB/YPBPR/YCBCR
    • Terminals | Serial/Multi Projector Sync In: D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
    • Terminals | Serial/Multi Projector Sync Out: D-sub 9-pin (male) x 1 for link control
    • Terminals | REMOTE 1 IN: M3 x 1 for wired remote control
    • Terminals | REMOTE 1 OUT: M3 x 1 for link control (for wired remote control)
    • Terminals | Remote 2 In: D-sub 9-pin (female) x 1 for external control (parallel)
    • Terminals | DIGITAL LINK: RJ-45 x 1 for network and DIGITAL LINK connections (HDBaseT™ compliant), PJLink™
      (Class 2) compatible, 100Base-TX, Art-Net compatible, HDCP 2.2 compatible, Deep Color compatible, 4K/60p signal input*5
    • Terminals | LAN: RJ-45 x 1 for network connection, PJLink™ (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible
      *1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped. *2 Average light-output value of all shipped products measured at center of screen in Normal Mode. *3 Around
    • this time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast contents, Normal Mode, Dynamic Contrast [3],


  • GTIN:

    0885170374287
