Palmer Audio PLI02 Line Isolation Box 2 Channel

ITEM #: PLM-PLI02 MFG #: PLI02

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Our Price:

$199.99

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


PLI02 - Overview

Two-channel isolation transformer (line isolator). Neutrik combination socket input (XLR & jack socket) and XLR output. The PLI02 also has a ground-lift switch. Especially suitable for eliminating ground loops that cause hum. Conversion from unbalanced to balanced is possible. 600 ? version can handle levels up to +20 dBu. Professional dual channel line isolating unit for stage and studio use. A unique Neutrik input connector accepts both male XLR and jack plugs. The PLI-02 easily converts unbalanced outputs into balanced ones. It may also be used to transformer balance electronically balanced inputs and outputs.

  • Features:

    • 2 channel isolation transformer + Neutrik connectors + Eliminates ground loops + Neutrik input connector accepts both male XLR + 1/4" jack plugs

  • Specifications:

    • Product type: line isolator
    • Type: passive
    • Channels: 2
    • Inputs: 2
    • input connectors: 2 x XLR/6.3 mm TRS combo
    • input type: balanced/unbalanced (depending on TS/TRS connection)
    • input impedance: 600 Ohm(s)
    • max. input level: + 20 dBu
    • Outputs: 2
    • output connectors: 2 x XLR
    • output type: balanced/unbalanced (depending on TS/TRS connection)
    • output impedance: 600 Ohm(s)
    • max. output level: + 20 dB
    • transformer balanced: yes
    • Ratio: 1:1
    • Frequency response: 20 - 20.000 Hz
    • controls: ground lift
    • cabinet material: die-cast aluminium
    • Cabinet / Housing surface: powder coated

  • GTIN:

    4049521049316
