PreSonus Quantum HD8 1RU 26x30 32-bit 192 kHz USB-C Low-Latency Audio Interface with AX-HD Mic Preamps +75 dB Gain Range

ITEM #: PRE-QUANTUM-HD8 MFG #: QUANTUM HD8

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$1,299.99

Our Price:

$999.99

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    QUANTUM HD8 - Overview

    Power your project with the PreSonus Quantum HD 8 - the recording interface for project studios and full band recordings.

    The Culmination Of 30 Years Of Innovation
    The HD 8 features eight newly redesigned high-definition MAX-HD mic preamps with +75 dB of gain - making it ideally suited for today's most popular microphones. Guitarists and bassists will love the instrument inputs, which were co-developed with Fender engineers. An Auto Gain button sets the perfect gain level for your microphones and instruments. You also get two re-amp outputs so you can send audio from your DAW to your guitar or bass amp and re-record it to experiment with different amps, pedals, and mic placements. An illuminated push encoder provides flexible control over gain level and output volume, and bright and responsive LED metering provides easy visual feedback for your outputs - making it great for self-produced recording.

    High Performance Signal Flow
    PreSonus's custom low-latency driver provides exceptionally low audio latencies when recording, and high-performance converters with 124 dB dynamic range let you hear and capture audio with stunning clarity and fidelity.

    All-New MAX-HD Mic Preamps
    The Quantum HD 8 features eight newly designed mic preamps with +75 dB of gain. PreSonus's high-definition MAX-HD preamps are transparent, low-noise, and digitally-controlled analog, making them ideally suited to today's most popular microphones.

    Co-Developed With Fender®
    Built by the best ears in the business, guitarists and bassists will love the instrument inputs, co-developed with Fender engineers - industry experts who designed them specifically for guitar and bass.

    Professional Recording Software Included
    Leap into 12 months of Studio One+ add-ons, exclusive content, and tools, plus a perpetual license to Studio One Professional Edition.

    Auto Gain
    An Auto Gain button sets the perfect gain level for your microphones and instruments, so you get the perfect take every time.

    Re-Amp Outputs
    Re-amp audio directly from your DAW and use amps and effects to sculpt your sounds. Send audio from your DAW to your guitar or bass amp and re-record it to experiment with different amps, pedals, and mic placements.

    Universal Control App
    Quantum interfaces work on any mobile or desktop device, so you're ready to record whenever inspiration strikes - whether on your phone, tablet, or in your home studio. Critical preamp functions like preamp gain, phantom power, and more can be controlled with the Quantum HD 8's flexible front panel, or right from Studio One and the Universal Control app, so you can dial in the perfect gain staging without looking away from your recording session.

    • Features:

      • 26 x 30, 32-bit / 192 kHz USB-C Audio Interface
      • High-performance converters with 124 dB dynamic range let you hear and capture audio with stunning clarity and fidelity
      • A custom low-latency driver provides exceptionally low audio latencies when recording
      • Eight all-new, next-generation PreSonus MAX-HD preamps provide transparency and accuracy across the frequency range with +75 dB of gain to maximize the performance of today's most popular microphones for modern recording and broadcast
      • 2 Re-amp outputs let you send audio from your DAW to your favorite outboard gear and record it again so you can experiment with different amps, pedals, and mic placement to get the exact sound you want without cutting multiple takes
      • Control your Quantum HD 8 right from Studio One and the Universal Control app, in addition to hardware, so you can adjust preamp gain, toggle phantom power, channel settings, and more without looking away from your recording session. Perfect for dialing in optimal gain staging
      • Universal Control and your Quantum HD 8 also enable speaker switching-easily check your mixes on two different speaker sets for accuracy
      • 16 channels of ADAT Optical input (up to 48 kHz) plus stereo S/PDIF I/O make connecting your digital gear fast and easy
      • ADAT standalone mode adds 8 pres and 10 outputs to your existing audio interface - so you can connect up to two additional Quantum HD 8s through ADAT for a total of 24 mic pres at sample rates up to 48 kHz

    • Specifications:

      • Controls/Connections
      • Headphone Jack: Two - 1/4" TRS Female Stereo
      • Connectivity: USB-C, MIDI I/O, 5-Pin Female DIN
      • Digital Audio Connections: Word Clock IO, BNC Connector, 4.5 Vpp @ 75Ω Load, SPDIF IO, RCA 75Ω Coax, ADAT Optical IO, Toslink Connectors, ADAT/SMUX Formats

        Mic Preamp
      • Mic Input Connection Type: XLR Female (Combo), Balanced
      • Total Harmonic Distortion: 0.002%)
      • Gain Control Range: 75 dB
      • Max Input Level: +18 dBu
      • Phantom Power: +48 VDC
      • Freq. Response: 20 Hz to 20 kHz, +/- 0.1 dB
      • Input Impedance: 1600 Ohms
      • Dynamic Range: 116 dB
      • Equivalent Input Noise: -130 dBu

        Instrument Inputs
      • Impedance: 1M Ohms
      • Max Level: +21 dBu
      • Gain Range: 75 dB
      • Freq. Response: 20 Hz to 20 kHz, +/- 0.1 dB
      • Dynamic Range: 111 dB
      • Total Harmonic Distortion: 0.003%

        Line Inputs
      • Max Level: +18 dBu
      • Gain Range: +/- 10 dB
      • Freq. Response: 20 Hz to 20 kHz, +/- 0.1 dB
      • Dynamic Range: 118 dB
      • Total Harmonic Distortion: 0.001%
      • Impedance: 10K Ohms

        Main/Line Outputs
      • Max Level: +18 dBu (Balanced)
      • Freq. Response: 20 Hz to 20 kHz, +/- 0.2 dB
      • Total Harmonic Distortion: 0.001%
      • Dynamic Range: 123 dB
      • Output Impedance: 51 Ohms
      • Connection Type: 1/4" TRS Female

        Headphone Outputs
      • Max Output: 11 dBu (50 Ohms)
      • Freq. Response: 20 Hz to 20 kHz, +/- 0.3 dB
      • Dynamic Range: 118 dB (A-Weighted)
      • Total Harmonic Distortion: 0.001% (1 kHz)
      • Headphone Outputs Impedance Working Range: 33 Ohms

        Digital Audio
      • Dynamic Range: 124 dB
      • Bit Depth: 32-bit
      • Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192 (kHz)

        Weights/Dimensions
      • Height: 1.7"
      • Depth: 8.6"
      • Width: 19"
      • Weight: 6.3 lbs

    • Item Includes:

      • 1x Quantum HD 8 Audio Interface
      • 1x Quantum HD 8 Quick Start Guide
      • 1x 1.5M USB-C to USB-C cable
      • 1x IEC Cable
      • 1x Safety and Compliance Guide

    • GTIN:

      0673454012211
