PreSonus Studio 1824c 18x24 USB-C Audio Interface /24-bit/192kHz with 8 Mic inputs ADAT I/O and Studio One Artist

ITEM #: PRE-STUDIO-1824C MFG #: STUDIO 1824C

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$649.99

Our Price:

$499.99

After Savings:

$429.99

Availability: In Stock
iAvailability Description Popup
Presonus Fall Savings on the Studio 1824C!Order today and save $70!


STUDIO 1824C - Overview

Created for demanding producers.
The PreSonus Studio 1824c 192 kHz USB-C audio interface is ideal for producers interested in recording full bands, including multi-channel drums. It records up to 18 simultaneous inputs and features 8 XMAX Class A mic preamps, as well as MIDI I/O. Its 20 outputs offer flexible routing with zero-latency DSP-based monitor mixing and control-room integration with included Studio One® Artist music production software and UC Surface control software.

World-class recording software included.
Seamlessly integrated with the included PreSonus UC Surface control software for macOS®, Windows®, iPad®, and Android™ tablet and Studio One Artist music production software, the Studio 1824c audio interface works with virtually all macOS and Windows recording software. Easy to learn, Studio One enables you to compose, record, and produce without getting distracted by the tools. Need a new loop or sample for your latest production? Studio One lets you shop, audition, and purchase new content right from your production environment-including powerful extensions for Studio One like the CTC-1 Console Shaper and Presence XT Editor.

Take the tour.
The Studio 1824c audio interface features USB-C computer connectivity and records up to 18 simultaneous inputs, including two combo mic and switchable line/instrument inputs and six mic/line inputs, all with XMAX mic preamps and +48V phantom power. Digital inputs include eight channels of ADAT Optical I/O (four channels at 96kHz) and stereo S/PDIF I/O. In addition to the main L/R outputs, you get eight DC-coupled line-level outputs that can send control voltages. You also get two headphone outputs. A built-in MIDI interface enables connection to a keyboard, sound module, or control surface.

Superior sound.
The Studio 1824c audio interface operates at up to 192kHz for ultra-high-definition mixing and recording. High-quality converters on every input and output and PreSonus' professional-grade XMAX mic preamps deliver incredibly high headroom, deep lows, smooth highs, and a rich overall sound.

Includes Studio Magic Plug-in Suite.
This suite of plug-ins adds a wealth of fresh sounds and effects to Studio One. Cherry-picked from the first names in virtual instruments and effects, each plug-in brings a different flavor of practical magic to your songs. These plug-ins aren't gimmicky one-trick ponies - these are real-deal workhorses that you'll rely on for countless mixes.

  • Features:

    • Up to 18 inputs/20 outputs simultaneously (8x8 @ 192kHz)
    • 2 mic/instrument/line inputs with XMAX Class A mic preamps
    • 6 mic/line inputs with XMAX Class A mic preamps
    • 8 channels of ADAT Optical I/O (4 channels @ 96kHz)
    • 2 balanced 1/4" TRS main outputs
    • DC coupled for sending control voltages
    • 8 balanced 1/4" TRS line outputs for monitor mixing
    • DC coupled for sending control voltages
    • 2 stereo headphone outputs with individual level controls
    • Stereo S/PDIF digital I/O
    • 1 USB-C 2.0 port
    • BNC word clock output
    • Studio One® Artist for Mac® and Windows®
    • UC Surface control software for Mac, Windows, iPad®, and Android™
    • Studio Magic Plug-in Suite
    • 18x8 onboard DSP monitor mixer
    • Front-panel level controls for main outputs
    • Mono and Mute buttons for the main outputs
    • True +48V phantom power for condenser microphones (global)
    • 10 ladder-style 8-LED level meters (8 input, 2 main output)
    • USB-C port (USB 2.0)
    • 24-bit resolution
    • 44.1, 48, 88.2, 96, 176.4, and 192kHz sampling rates
    • 1U rack-mountable
    • Road-rugged construction with all-metal chassis and metal knobs

  • Specifications:

    • General
    • Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192kHz
    • Converter Resolution: 24-bit
    • Converter Dynamic Range: 114dB
    • Converter Dynamic Range: 114dB

      Mic Inputs
    • Maximum Level: +16dBu, min gain
    • Gain Range: 80dB
    • Frequency Response: 20Hz - 20kHz (unity gain)
    • Dynamic Range: 110dB (A-wtd, min gain)
    • THD + N: 0.005% (1kHz, 0dBu, unity gain)
    • EIN: -128dBu (A-wtd, 20kHz BW, Rs=150Ω, max gain)
    • Input Impedance: 1400Ω
    • Phantom Power: 48V (>10mA per channel)

      Line Inputs
    • Maximum Level: +21dBu (balanced, min gain)
    • Gain Range: 40dB
    • Frequency Response: 20Hz - 20kHz (unity gain)
    • Dynamic Range: 112dB (A-wtd, min gain)
    • THD + N: 0.005% (1kHz, +18dBu, min gain)
    • Input Impedance: 10kΩ

      Instrument Inputs
    • Maximum Level: +15dBu (unbalanced, min gain)
    • Gain Range: 80dB
    • Frequency Response: 20Hz - 20kHz (min gain)
    • Dynamic Range: 112dB (A-wtd, min gain)
    • THD + N: 0.020% (1kHz, +10dBu, min gain)
    • Input Impedance: 1MΩ

      Main Outputs
    • Type: 1/4" TRS female, DC Coupled
    • Maximum Level: +18dBu, balanced
    • Frequency Response: 20Hz - 20kHz (unity gain)
    • Dynamic Range: 108dB (A-wtd, unity gain)
    • THD + N: 0.004% (1kHz, -1dBFS, unity gain)

      Line Outputs
    • Type: 1/4" TRS female, DC coupled
    • Maximum Level: +18dBu, balanced
    • Frequency Response: 20Hz - 20kHz
    • Dynamic Range: 108dB (A-wtd, -60dBFS)
    • THD + N: 0.004% (1kHz, -1dBFS, unity gain)

      Headphone Outputs
    • Maximum Power: 150mW/channel (60Ω load)
    • Frequency Response: 20Hz - 20kHz (unity gain)
    • Dynamic Range: 103dB (A-weighted, 1kHz, unity gain)
    • THD + N: 0.250% (1kHz, 150mW, unity gain)
    • Impedance Working Range: 32Ω - 600Ω

      Physical:
    • Dimensions (HxWxD): 1.75" x 19" x 5.5" (44mm x 483mm x 140mm)
    • Weight: 4.8lbs (2.2kg)

  • Computer System Requirements

    :

    • Mac
    • Mac® OS X 10.8.5 64-bit or later
    • Intel® i-series 2GHz multicore processor (or AMD equivalent) or faster
    • 4GB RAM (8GB or more recommended)

      Windows
    • Windows® 7 x64/x86 SP1 + platform update, Windows 8.1 x64/x86, Windows 10 x64/x86
    • Intel i-series 2GHz multicore processor (or AMD equivalent) or faster
    • 4GB RAM (8GB or more recommended)

      Mac & Windows Systems
    • USB-C or USB-A 2.0 port
    • 32GB hard disk space
    • PreSonus Universal Control 2.0 or higher
    • Monitor with 1366 x 768 resolution (high-dpi monitor recommended)
    • Multitouch-enabled monitor required for touch operation

  • GTIN:

    0673454008078
