Pure Resonance Audio VCA8 Vector Lay-In 2x2 Drop Ceiling Speaker Array 8 Ohm Input

ITEM #: PRES-VCA8 MFG #: VCA8

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$347.99

Our Price:

$289.99

Availability: 2+ Weeks.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


VCA8 - Overview

The Pure Resonence VCA8 Vector Ceiling Array takes ceiling speaker performance to a new level. The Vector is an innovative speaker concept that meets the demanding needs of audio sound systems. Vector Speakers' pyramid design fits into standard 2'x2' or 2'x4' ceiling tile grids, providing an amazing 360 degrees of hemispheric sound. Vector ceiling speakers are quick and economical to install and are competitively priced, making them an excellent value to contractors!

The Vector 2 x 2 Lay-In Ceiling Speaker employs (3 smaller 6.5") very fast transient response aluminum-woofer drivers that are very powerful and stable. Working in unison these drivers produce clean powerful dynamic sound.

When designing the Vector the goal was to have the single most import feature at the forefront, good transient response ("dynamic contrast"). A transient is a sound of short duration, and good transient response can only be achieved if the speaker can deliver its output quickly and cleanly without smearing the original sound, and be completely soundless immediately after. Transients contain the essentials of sound reproduction they provide the sharp pop from a snare drum, the cutting edge of digital sound, the dynamics of the human voice. Larger 2-way cabinet loudspeaker systems offer relatively slow transient response, and the small high-frequency horn tends to beam a narrow, blaring sound at the listener-end result, muddy sound. By replacing larger speakers with four 6" drivers we increased the driver surface area while creating more punch and a tight, more focused low-end.

  • Features:

    • Omni Directional Speaker Coverage 360 x 180 (hemispherical).
    • Drops into standard ceiling tile openings.
    • Powerful 120 Watts at 8 Ohms
    • 3 - 6.5" High compliance aluminum woofers with ported bass response and high frequency dome tweeters.
    • Uniquely designed fire retardant ABS housing may be painted to match any decor
    • Impedance: 8 Ohms

  • Specifications:

    • System Type: Omni Directional 2 x 2 Ceiling Speaker Array
    • Power Handling: 120W
    • Frequency Response: 35Hz - 20kHz
    • Sensitivity: 92dB (half space)
    • Impedance:
    • Woofers: 6.5" Aluminum
    • Dispersion: 180° x 360° (hemispherical)
    • Driver Complement: Array of three full-range 6.5" drivers
    • Dimensions (WxHxD): 23.75 x 23.75 x 4.75 inches
    • Net Weight: 16lbs
    • Shipping Dimensions (WxHxD): 28" x 28" x 9.25"
    • Shipping Weight: 18lbs
