RME M32 AD PRO II 32-Channel High-End 192 kHz AD Converter with MADI and AVB

ITEM #: RME-M32-ADPRO-II MFG #: M32 AD PRO II

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
RME Audio
Free Shipping with $49 Minimum Order

List Price:

$4,499.00

Our Price:

$3,999.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

M32 AD PRO II - Overview

The RME M-32 AD Pro II (Part of the M-32 Pro II Series) is designed to meet the demanding requirements of professional studios, immersive sound installations, live sound systems, and industrial applications that need a reliable solution for analog conversion with high-end network audio processing. These new converters are available with either 32 analog inputs or outputs, and either with Dante® or AVB for a choice of four different models.

Boasting up to 32-channels, fully equipped MADI I/Os (coaxial & optical via optional SPF module), improved specs with extremely low THD values, intelligent channel routing and innovative usability, the brand-new M-32 Pro II Series truly represents the state-of-the art in exceptional audio performance.

  • Features:

    • 32 x Analog In/Out (25-pin D-sub, up to +24 dBu)
    • 2 x MADI I/O (via optional available optical SFP and coaxial BNC, up to 128 Ch.)
    • 2 x RJ45 1 GigE AVB, four streams with 4/8/12/16 Ch. each
    • Word Clock I/O (BNC)
    • 2 x monitored fully redundant internal PSUs
    • 32-channel AD converter, fully symmetrical design, 120 dBa
    • 19" enclosure 1 unit height
    • Large, tri-color backlit channel indicators with Peak/RMS metering
    • Magnetic cover with customizable channel labels
    • SyncCheck® and ICC® - detects when a clock source is not in sync and falls back to other available signals
    • MADI Auto-Input - seamless redundancy
    • 2" display with control knob for full device control
    • 15 Preset storage, firmware upgrade persistent
    • Lock (optional code) and dark mode
    • Internal routing of up to 224x192 M-32 AD Pro / 192x224 M-32 DA Pro channels in 4 channel blocks (32 x Analog, 64 x MADI Opt, 64 x MADI Coax, and 64 x AVB)
    • Remote control via HTTP, JSON, IEEE 1722.1 AVDECC ] MIDI over MADI and optional MIDI


  • Specifications:

    • M-32 Pro II AD Line In 1-32:
    • Resolution: 24 bit
    • Input level switchable per channel +24 dBu, +19 dBu, +13 dBu @ 0 dBFS
    • Inputs AC coupled, fully symmetrical signal path (servo-balanced)
    • Signal to Noise ratio (SNR) @ +24 dBu, 44.1 kHz: 117.0 dB RMS unweighted, 120.7 dBA
    • Signal to Noise ratio (SNR) @ +19 dBu: 116.3 dB RMS unweighted, 119.9 dBA
    • Signal to Noise ratio (SNR) @ +13 dBu: 114.7 dB RMS unweighted, 118.3 dBA
    • Frequency response @ 44.1 kHz, -0.1 dB: 5 Hz - 20.5 kHz
    • THD @ -1 dBFS: < -111 dB, < 0.00029%
    • THD+N @ -1 dBFS: < -108 dB, < 0.00039 %
    • Channel separation: > 110 dB
