RME M32 DA PRO II-D 32-Channel High-End 192 kHz DA Converter with Dante and MADI

ITEM #: RME-M32DAPRO-IID MFG #: M32 DA PRO II - D

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
RME Audio
Free Shipping with $49 Minimum Order

List Price:

$4,999.00

Our Price:

$4,599.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

M32 DA PRO II - D - Overview

The RME M-32 DA Pro II-D (Part of the M-32 Pro II Series) is designed to meet the demanding requirements of professional studios, immersive sound installations, live sound systems, and industrial applications that need a reliable solution for analog conversion with high-end network audio processing. These new converters are available with either 32 analog inputs or outputs, and either with Dante® or AVB for a choice of four different models.

Boasting up to 32-channels, fully equipped MADI I/Os (coaxial & optical via optional SPF module), improved specs with extremely low THD values, intelligent channel routing and innovative usability, the brand-new M-32 Pro II Series truly represents the state-of-the art in exceptional audio performance.

  • Features:

    • 32 x Analog In/Out (25-pin D-sub, up to +24 dBu)
    • 2 x MADI I/O (via optional available optical SFP and coaxial BNC, up to 128 Ch.)
    • 2 x RJ45 for Dante network connectivity (up to 64 channels)
    • (optional) MIDI I/O for legacy MIDI Remote
    • Word Clock I/O (BNC)
    • USB 2.0 (for remote control)
    • 2 x monitored fully redundant internal PSUs
    • 32-channel AD converter, fully symmetrical design, 120 dBa
    • 19" enclosure 1 unit height
    • Large, tri-color backlit channel indicators with Peak/RMS metering
    • Magnetic cover with customizable channel labels
    • SyncCheck® and ICC® - detects when a clock source is not in sync and falls back to other available signals
    • MADI Auto-Input - seamless redundancy
    • 2" display with control knob for full device control
    • 15 Preset storage, firmware upgrade persistent
    • Lock (optional code) and dark mode
    • Remote control via HTTP, JSON, MIDI over MADI and optional MIDI


  • Specifications:

    • M-32 Pro II-D DA Line Out 1-32:
    • Resolution: 24 bit
    • Output level switchable per channel +24 dBu, +19 dBu, +13 dBu @ 0 dBFS
    • Outputs DC coupled, fully symmetrical signal path ("truly balanced")
    • Output impedance: 200 Ohm balanced, 100 Ohm unbalanced
    • Signal to Noise ratio (SNR) @ +13/+19/+24: 116 dB RMS unweighted, 119 dBA
    • Frequency response @ 44.1 kHz, -0.1 dB: 0 Hz - 22 kHz
    • THD @ -1 dBFS: < -109 dB, < 0.00035 %
    • THD+N @ -1 dBFS: < -107 dB, < 0.00043 %
    • Channel separation: > 110 dB
