Smart-AVI DFX-XT-2P-RX 2x 4K HDMI USB 2.0 and Audio KVM via Single Mode Dual Fiber Receiver - Up to 6.2 Miles

ITEM #: SAVI-DFX-XT-2PRX MFG #: DFX-XT-2P-RX

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Our Price:

$799.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


DFX-XT-2P-RX - Overview

The Smart-AVI DFX-XT-2P-RX is a Dual Head HDMI (3840 x 2160), USB 2.0, USB keyboard-mouse and stereo audio receiver, receiving signals up to 10 km (6.2 miles) away over a single conventional and inexpensive a dual fiber cable. This new technology is superior to older HDMI receivers that require a special dual fiber shielded cable to go a short distance.

The DFX-XT-2P-RX is the first receiver on the market to feature 3840 x 2160, USB 2.0 and full KVM extension on one cohesive system and is optimized for Full HD monitors with crystal-clear picture; excellent for detail driven work.

The DFX-XT-2P-RX receives keyboard-mouse signals for remote workflow management and offers uninterrupted emulation from the user's receiver unit. This uninterrupted emulation prevents accidental disconnection or deactivation issues during mission critical operations. The DFX-XT-2P-RX's unparalleled KVM receiving technology makes it the perfect solution for extending servers in applications ranging from data processing to interactive conferencing.

Audio and Visual Recording
For users in the recording arts, maintaining the utmost in signal and recording fidelity is an absolute necessity. For video recording, it is often important that no unsightly computers are visible. Similarly, audio engineers must keep noisy computers away from the rooms where recording happens to ensure the final product sounds professional. In both such instances, the DFX-XT-2P-RX gives users the ideal way to keep their servers or computers away from areas that audio or video recording is being done, ensuring a better final product.

  • Features:

    • Extends HDMI up to 10 km (6.2 miles) in the Single Mode and up to 500 m (1640.42 feet) in the Multi Mode from the source
    • HDCP Support
    • Supports up to 3840 x 2160 digital video resolution @ 30 Hz
    • USB Keyboard and Mouse extension
    • Uncompressed Video
    • External power adapter for transmitter and receiver unit
    • Supports Stereo Sound
    • Compatible with Windows, Mac and Linux Operating Systems
    • Transparent USB 2.0 extension

  • Specifications:

    • Video
    • Format: HDMI2.0
    • Video Resolution:
      - Resolution: high definition 3840 x 2160
      - Color Depth: 24-bit color depth
      - Latency: less than 1 ms
    • Video Bandwidth: Single-link 340 MHz (10.2 Gbps)
    • Input Interface: (2) HDMI 19-pin (female)
    • Output Interface: (2) HDMI 19-pin (female)
    • Max Output Distance: Up to 20 f
    • Equalization: Automatic
    • Input TMDS Signal: 1.2 Volts [peak-to-peak]
    • Input DDC Signal: 5 Volts [peak-to-peak, TTL]
    • Data Rate: 1.65 Gbps per color

      Audio
    • Format: Stereo
    • Input Interface: 3.5 mm Jack Socket (female)
    • Output Interface: 3.5 mm Jack Socket (female)

      USB
    • Output Interface (RX): (2) USB 1.1 Type A for KM Devices; / (2) USB 2.0 Type A Transparent
    • Keyboard and Mouse: Keyboard and mouse emulation

      System
    • Fiber Interface & Type: Single-Mode Fiber
    • Cable Requirements: Dual Fiber
    • Maximum Length:
      - Single mode: 10 km (6.2 miles)
      - Multi mode: 500 m (1640.42 feet)

      Other
    • Power: 100-240 VAC/ 5VDC @ 3A/15W
    • Dimensions(WxHxD): 7.8 x 1.15 x 3.65 In (198.12 x 29.21 x 92.71 mm)
    • Weight: .5 lbs (.23 kg)
    • Approvals: UL, CE, ROHS Compliant
    • Operating Temp.: +32 to 104 °F (0-40 °C)
    • Storage Temp.: 4 to 140°F (-20 to +60°C)
    • Operating Humidity: 20% to 80% (non condensing)
    • Storage Humidity: Up to 95% (No Condensation)
    • Compliance: EMC FCC (Class A), CE (Class A), ICES-003
    • Environmental Compliance: RoHS2 (CE)

  • Item Includes:

    • 1x DFX-XT-2P-RX Unit
    • 1x Power Adapter
    • 1x User Manual

  • Warranty:

    • 1 Year Warranty
