Smart-AVI FVX-3000-PRO DVI-I (DVI/VGA) / Stereo Audio / USB / RS-232 / KVM Multimode Fiber Extender - up to 10km

ITEM #: SAVI-FVX-3000PRO MFG #: FVX-3000-PRO

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Smart-AVI
Free Shipping with $49 Minimum Order

List Price:

$2,999.00

Our Price:

$2,399.20

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

FVX-3000-PRO - Overview

What is the FVX-3000-Pro?
The Smart-AVI FVX-3000-PRO is a single-mode fiber extender for VGA video, stereo audio, RS-232, and USB keyboard-mouse signals. Using its powerful fiber optic technology, the FVX-3000-PRO sends 1080p (1920x1080 @ 60Hz) Full HD audio-video and keyboard-mouse signals up to 10km (6.2m) away at lightning fast speeds without the risk of interference or interception.

What are the Applications of the FVX-3000-Pro?
The FVX-3000-Pro excels at transmitting and receiving HD VGA signals over long distances at incredible speeds. Outfitted with fiber optic cables popular in military and government operations, the FVX-3000-Pro is secure and resistant to outside interference. It can be used for KVM activities in businesses, corporations, industrial control rooms, hospitals, server hubs, banking facilities, and more. The FVX-3000-Pro also excels at securely sending confidential media and files across systems thousands of feet apart, ideal for communications, asset delivery, and remote access to sensitive digital materials.

Applications:
Industrial Control Rooms
Isolated Long-Range Workstations
Corporate Communications
Remote Asset Management
Long-Range KVM Applications
Medical Communication and Administration
Financial Management & Communications

  • Features:

    • Single-mode fiber optic extension up to 10km (6.2m)
    • Supports VGA
    • Supports video resolutions up to 1080p Full HD (1920x1080 @ 60Hz)
    • Supports USB 2.0 (keyboard-mouse only)
    • Supports stereo audio
    • Supports RS-232
    • Supports all computer operating systems
    • Compact, durable chassis


  • Specifications:

    • Video Data
    • Format: VGA Female
    • Input: (1) VGA Female
    • Output: (1) VGA Female
    • Max. Pixel Clock: 165 MHz
    • Max. Data Rate: 6.75 Gbps
    • Resolution: Up to 1080p (1920x1080 @ 60Hz)
    • Input Cable Length: Up to 20 ft.
    • Output Cable Length: Up to 20 ft.

      Audio
    • Input: (1) 3.5mm stereo audio jack
    • Output: (1) 3.5mm stereo audio jack

      USB
    • Signaling: USB Keyboard-Mouse Only
    • Input: (1) USB Type-B
    • Output: (2) USB Type A

      RS-232
    • Signal Direction: Unidirectional
    • Max. Baud Rate: 115200bps (self-adaptive)
    • Data Bits: 8

      Other
    • Power Adaptor: 12VDC2A
    • Dimensions: 6.25" W x 1.875" H x 5.0" D
    • Weight (TX & RX): 1.45 lbs (0.725 lbs per unit)
    • Approvals: UL, CE, ROHS Compliant
    • Fiber Interface & Type: LC Single-Mode Fiber
    • Transmission Distance: Up to 10km (6.2 miles)
    • Working Temperature: 32 to 122°F (0 to 50°C)
    • Storage Temperature: -4 to 149 °F (-20 to 65°C)
    • Working Humidity: Up to 85% RH (no condensation)
    • Storage Humidity: Up to 90% RH (no condensation)


  • Item Includes:

    • 1x FVX-TX3000P: VGA/Audio/RS-232/USB KM Transmitter
    • 1x FVX-RX3000P: VGA/Audio/RS-232/USB KM Receiver
    • 2x PS12VDC2A Power Supplies
    • 1x Quick Start & Installation Guide
