Smart AVI HDR-4X4-PLUS 4K Resolution 4x4 HDMI Matrix Switcher with IR Remote & RS232 Control

ITEM #: SAVI-HDR-4X4-PLS MFG #: HDR-4X4-PLUS-S

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Smart-AVI
Free Shipping with $49 Minimum Order

Our Price:

$799.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

HDR-4X4-PLUS-S - Overview

The Smart AVI HDR-4X4-PLUS delivers switching four (4) HDMI signals between four (4) displays or recording devices in the latest 4K (3840x2160 @30Hz) HDMI video signals formats. The HDR-4x4-Pro eliminates the need to disconnect and reconnect HDMI sources to a single display. The device is compatible with computer sources, live HD television feeds, Blu-ray players, gaming consoles, video cameras and more. Controlling the matrix switch is simple with the front-panel buttons, the included infrared remote control and the RS-232 port.

  • Features:

    • Supports 4K/2K Input/Output
    • 4x4 Non-Blocking, HDMI Matrix Switch
    • Distributes Any of the Four Inputs to Any of the Four HDMI Output Displays
    • EDID Learning Mode
    • Includes IR Remote
    • Supports RS-232 Control
    • HDCP and HDMI 1.4 Compliant


  • Specifications:

    • Format: HDMI
    • DVI Compliance: Single-link DVI-D 1.1 with Adapter
    • HDCP Compliance: 1.0/1.1
    • Video Bandwidth: Single-link 340MHz [10.2Gbps]
    • Resolution: Up to 3840x2160 @30Hz
    • Input Interface: (4) HDMI [7.1ch audio & video]
    • Output Interface: (4) HDMI [7.1ch audio & video]
    • Connector: Type A [19-pin female]
    • CONTROL: Front Panel Tact Switch
    • IR CONTROL: Via Remote Control with IR Type 3
    • PC CONTROL: RS-232 Control
    • Power: External 100-240 VAC/5VDC2A @10W
    • Dimensions: 11.8 in (W) x 1.25 in (H) x 5 in (D)
    • Weight: 1.5 lbs
    • Approvals: UL, CE, ROHS Compliant
    • Operating Temp.: 32-131 °F (0-55 °C)
    • Storage Temp.: -4-185 °F (-20-85 °C)
    • Humidity: Up to 95%


  • Item Includes:

    • HDR-4X4-Plus Switcher
    • SRC-2A Remote Control
    • PS12VDC4A Power Supply
