Sennheiser EW-DX SKM R1-9 Handheld Transmitter - Frequency 520 - 607.8 MHz

ITEM #: SENN-EWDXSKM-R19 MFG #: 509427

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Sennheiser
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$549.00

Our Price:

$469.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

509427 - Overview

Sennheiser EW-DX SKM (R1-9) rugged and versatile handheld transmitter without switch. The R1-9 has a frequency of 520 - 576 MHz.

Focus less on the wireless and more on the audio. Sennheiser EW-DX simplifies your professional workflow by utilizing refined technologies and decades of expertise to deliver a digital UHF system that can be scaled with ease. Multiple hardware and software options create networkable solutions for nearly any stage or campus, while equidistant channel spacing, auto scan, and Bluetooth® Low Energy sync automatically coordinate and set frequencies with the push of a button. Monitor your devices from a distance-even from your pocket-with tools like Sennheiser Control Cockpit, Wireless Systems Manager, and the Smart Assist app. The future of wireless is here.

Applications
Education
Corporate
Performers
Houses of Worship
Rental Houses
Theaters
Broadcast Studios
Presentations/Lectures
Meetings
Live Sound

Please note! Capsule sold seperately.

  • Features:

    • EW-DX SKM
    • 10mW RF power with up to 100m/328ft working range
    • Charging contacts for in-device charging with CHG 70N
    • Persistent eInk display - parameters visible on screen even when device is not powered on
    • Programmable mute switch on EW-DX SKM-S - customize the device depending on your professional needs
    • Function buttons - control all the transmitter settings directly from handheld microphone
    • Extended runtime with lithium-ion batteries - up to 12 hours operation time
    • Standard capsule interface - compatible with a wide range of Sennheiser and Neumann capsules
    • Mic input trim control
    • Metal housing


  • Specifications:

    • System
    • Audio Link Frequency Ranges
      Q1-9: 470.2 - 550 MHz
      R1-9: 520 - 576 MHz
      V5-7: 941.7 - 951.8 MHz & 953.05 - 956.05 MHz & 956.65 - 959.65MHz
    • Bluetooth® Low Energy (BLE) Frequency Range: 2402 - 2480 MHz
    • Audio frequency response: 20 Hz - 20 kHz (-3 dB) @ 3 dBfs
    • Audio THD: ≤ -60 dB for 1 kHz @ -3 dBfs input level
    • Dynamic Range: 134 dB
    • System Latency: 1.9 ms
    • Operating Temperature: -10°C - +55°C (14°F - 131°F)
    • Relative Humidity: 5 - 95 % (non-condensing)

      EW-DX SKM (Handheld Transmitter)
    • Input Voltage: 2.0 - 4.35 V
    • Input Current: < 300 mA
    • Power Supply: 2 AA batteries 1.5 V (alkali manganese) or BA 70 rechargeable battery pack
    • Occupied Bandwidth: 200 kHz
    • Transmit Power (Radiated):
      Audio link: 10 mW ERP (Range Y1-3: 12 mW ERP)
      LD mode: 10 mW ERP
      BLE: max. 10 mW EIRP
    • Dimensions (ø x l):
    • (Incl. MMD 835 Microphone Module): 50 x 268mm (1.97" x 10.55")
      (Without Microphone Module): 40 x 200mm (1.57" x 7.87")
    • Weight (Without Batteries):
      (incl. MMD 835 microphone module): approx. 304g (0.67Lbs)
      (without microphone module): approx. 195g (7.14Lbs)


  • Item Includes:

    • 1x EW-DX SKM handheld transmitter
    • 1x MZQ 1 microphone clamp
    • 2x Batteries (AA)
    • 1x Quick guide
    • 1x Safety guide
    • 1x Manufacturer declaration sheet


  • GTIN:

    0615104362819
