Skaarhoj W-BOARD-MINI-V1B-BK Wave Board Mini Universal Audio Mixing/Processing Fader Bank - Black

W-BOARD-MINI-V1B-BK - Overview

• Features:

  • Compact 4-channel fader bank for efficient audio control in limited spaces.
  • Tactile feedback with fader, 3 knobs, a vertical display, and an encoder per channel.
  • Universal compatibility with devices like Direct Out Prodigy.MP, Digico, Allen-Heath, AMPP Audio Mixer, and more.
  • Ideal for setups requiring high-quality audio control without occupying extensive space.
  • Extensive list of supported devices
  • Advanced ergonomics
  • Versatile connectivity via IP
  • Durable build quality
  • 4 Motorised faders
  • 4 assignable backlit encoders
  • OLED display for each channel showing live metering (if supported)
  • Three 2-way buttons for each channel strip
  • Four 4-way buttons
  • Widescreen OLED displays for each button and knob
  • Universal control of multiple 3rd party devices
  • User customization with Reactor Web UI
  • 1G Ethernet w/Power over Ethernet (PoE IEEE802.3af/t)
  • Designed and made in Denmark
  • Time tested - adopted by professionals worldwide


• Specifications:

  Hardware Specifications
  • Component Highlights: 60mm motorized faders
  • Buttons: Elastomer Four-Way Button (x4); Elastomer Two-Way Button (x12)
  • Encoders: Encoder (x4)
  • Analog Components: Motorized Fader 60mm (x4)
  • Programmable OLED Tiles: 64x48 pixels (x4); 88x32 pixels (x4); 256x32 pixels (x4); 32x32 pixels (x4); 176x32 pixels (x4); 32x24 pixels (x8)
  • Other: OLED Display Tile (x20)

    Connectivity
  • Networking: 1G Ethernet w/Power over Ethernet (PoE IEEE802.3af/t)
  • Power Supply: 12V DC Jack 5.5mm x 2.1mm x 10mm Center Positive PoE IEEE802.3af/t
  • Service Port: Micro USB for setting manual IP
  • Peripherals: USB-A 2.0 (500 mA) for Stream Deck, X-keys, additional networking adapters, frame grabbers etc.

    Software
  • Platform: Blue Pill (Reactor, Device Cores, skaarOS Linux)
  • Licenses: Full Reactor and Device Core licenses included


• Item Includes:

  • 1x 12V Power Supply


• Warranty:

  • 1 year


• GTIN:

  5714074003106
