Studiomaster CLUB XS16 Plus 12 Channel 12 Input Mixer

ITEM #: SM-CLUB-XS16P MFG #: CLUB XS16+

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$739.00

Our Price:

$565.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


CLUB XS16+ - Overview

The Studiomaster Club XS Compact, portable mixing consoles featuring 5 to 16 inputs, Bluetooth connectivity, on-board DSP effects and USB/SD card playback and recording functions.

3 band EQ, 2 auxiliaries, balanced mic/line connectors, compressor control, and a useful mute switch on all Mic and line input channels, and 2 band EQ with 2 auxiliaries for both stereo channels. There are also balanced XLR connectors for the main outputs, jack outputs for auxiliaries and control room, and phono connectors for record and playback.

Ultra compact, light weight, high quality and extremely versatile, the Club XS is the perfect mixer for any live performance and home recording situation .

  • Features:

    • 16 inputs
    • 12 mic channels
    • 2 stereo channels
    • 2 AUX sends
    • 16 DSP effects
    • Foot switch socket for DSP
    • PFL’s on all channels
    • Bluetooth
    • USB/SD media player

  • Specifications:

    • Inputs: 16
    • Mic Inputs: 12
    • Stereo Inputs: 2
    • Mic Gain Range: 6dB to 50dB
    • Line Gain Range: 10dB to 34dB
    • EIN: -100dB
    • Frequency Responce: 10Hz 20kHz (+1/-3dB)
    • THD Mic Channel: <0.1%
    • Signal to Noise Ratio: 80dB
    • Output Levels: Max +26dB (Bal), +20dB (unBal)
    • EQ: Hi 12kHz, Mid 2.5kHz, Lo 45Hz, Lo cut 80Hz
    • USB/SD: MP3 Audio playback
    • Record: To USB drive or SD card (128kbps mono)
    • DSP Effects: 16 DSP effects
    • Power Requirements: 100V 240V ~
    • Dimension W*D*H: 385 x 527 x 85 (mm)

  • GTIN:

    5060255344392
