Sony SRG-A12/N 4K PTZ Camera with 12x Optical Zoom/NDI HX/Built-In AI - Black

ITEM #: SNY-SRGA12-N MFG #: 61-SRGA12N

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Our Price:

$2,899.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


    61-SRGA12N - Overview

    The Sony SRG-A12/N includes revolutionary PTZ Auto Framing technology powered by built-in AI analytics ensures high-quality composed shots without an operator.

    A Camera that Automatically and Naturally Shoots Video for You
    With the advanced PTZ Auto Framing feature, the camera automatically tracks the person in a comfortable viewing with smooth pan, tilt and zoom movement regardless of posture, movement and what one is wearing.
    Since the camera does most of the work automatically, the operator can spend their time more efficiently.

    PTZ Auto Framing with Built-in AI Analytics
    This camera harnesses powerful AI-powered video analytics that can automatically detect and track the position of a presenter within the camera frame. As the presenter moves, the camera's pan, tilt and zoom mechanism ensures that the presenter is always framed naturally, without the need for a human camera operator to manually follow their movements.

    Automatically and Reliably Shoots Video for You
    With Sony's newly developed AI analytics algorithm, it detects the person's skeleton and head position and matches the person's detail features even when there are several people in the frame. It achieves accurate framing and consistent tracking.

    Keep Everyone in the Picture with Multi-Person Framing
    The SRG-A12 can automatically track a group of up to eight people, with a primary subject and secondary subjects. The primary subject can be specified via the camera's Face Registration function, or on the web app screen. The secondary subjects are automatically selected according to their proximity to the primary subject. The camera's pan, tilt and zoom function ensures that the selected people are included in the image, with natural looking framing. Multi-person Framing is ideal for various applications such as corporate conferences, panel discussions, weddings and other ceremonies.

    Integrated Tally Lamp
    The SRG-A12 features a built-in tally lamp, just like you'd find on professional studio cameras. The lamp illuminates to give presenters visual confirmation of shooting status, or to show that PTZ Auto Framing mode is active. The lamp color will change from Red (On Air) to Green (PTZ Auto Framing ON).

    • Features:

      • High speed Pan and Tilt
      • Wide angle zoom Lens
      • Powerful zoom, wide angle
      • PTZ auto framing
      • Preset camera positions
      • Picture freeze preset
      • AF, AE and AWB
      • PTZ motion sync

    • Specifications:

      • Camera
      • Image Sensor: 1/2.5 type ExmorR CMOS
      • Image Sensor (Number of Effective Pixels): Approx. 8.5M pixels
      • Signal System:
        - 2160/29.97p, 25p, 23.98p
        - 1080/59.94p, 50p, 29.97p, 25p, 23.98p
        - 1080/59.94i, 50i
        - 720/59.94p, 50p
      • 4K Capability: Yes
      • Minimum Illumination (50IRE): 1.6 lux (1/30s 50IRE F2 high-sensitivity OFF)
      • Horizontal Resolution:
        - 1700 TV lines (Center) (4K)
        - 1000 TV lines or higher (Center) (FHD)
      • Gain: Auto/Manual (0 to +48 dB)
      • Shutter Speed:
        - 1/1 to 1/10000 sec (59.94 Hz system)
        - 1/1 to 1/10000 sec (23.98 Hz system)
        - 1/1 to 1/10000 sec (50 Hz system)
      • Exposure Control: Auto/Manual/Priority AE (Shutter, Iris)
      • Focusing System: Auto/Manual
      • Horizontal Viewing Angle: Approx. 70.0 degree (Wide)
      • Focal Length: f=4.4 mm (Wide) to 88.0 mm (Tele)
      • F-Number: F2.0 to F3.8
      • Pan/Tilt Angle:
        - Pan: ±170°
        - Tilt: +90°/-20°
      • Pan/Tilt Speed (Max.):
        - Pan: 300°/sec
        - Tilt: 126°/sec
      • Pan/Tilt Slow Mode: Yes
      • Pan/Tilt Operation Noise: NC30 or less

        Network
      • IP Video Resolution: 3840 x 2160, 1920 x 1080, 1280 x 720, 640 x 360
      • Compression Format:
        - H.264: High/Main/Baseline Profile
        - H.265: Main Profile
      • Maximum Frame Rate:
        - H.264: 60fps
        - H.265: 60fps
      • Bitrate Compression Mode: CBR/VBR (selectable)
      • Range of Bitrate Setting: 512 kbps~50 Mbps
      • Multi-Streaming Capability: 3
      • Maximum Number of Clients: 5
      • Protocols: IPv4, IPv6, TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, VISCA over IP, SRT
      • NDI|HX Capability: Yes, License Included

        Audio
      • Channel: 2 ch
      • Audio Codec:
        - AAC LC 128 kbps/ST (IP)
        - AAC LC 256 kbps/ST (IP)
      • Embedded Audio in Baseband Video: Yes (3G-SDI, HDMI)
      • Embedded Audio in IP Streaming: Yes
      • 4K Video Output: 1x HDMI, 1x IP (streaming)
      • HD Video Output: 1x 3G-SDI, 1x HDMI, 1x IP (streaming)
      • SD Video Output: 1x IP (streaming)
      • Remote Video Format Switching: Yes
      • HDMI Color Space:
        - YCbCr, 4:2:2 8bit
        - RGB, 4:4:4 8bit
      • Camera Control Interface:
        VISCA RS-422 RJ45 (In/Out)
        VISCA over IP RJ45
      • IR Remote Control: Yes
      • Microphone Input: Stereo Mini-phone (Φ3.5 mm),(Mic/Line Selectable)
      • Sync. System: INT
      • Power Connector Type: IEC60130-10 (JEITA standard RC-5320A) Type5

        General
      • Power Requirements:
        - DC 19.5 V
        - PoE++ (IEEE802.3bt type4 class8)
      • Power Consumption:
        - DC19.5 V: 80W
        - PoE++: 71.3W
      • Operating Temperature: 32°F - 104°F (0°C - 40°C)
      • Storage Temperature: -4°F - 140°F (-20°C - 60°C)
      • Dimensions (WxHxD): 6.25" x 7.25" x 7.875" (156.7mm x 184mm x 200mm)
      • Weight: 4.4lbs (2.0kg)
      • Size of Screw Hole for Tripod: 1/4-20UNC
      • Mountable Angle: < ±15°

    • Item Includes:

      • 1x Sony SRG-A12 Auto Framing PTZ Camera - Black
      • 1x NDI|HX License
      • 1x AC power adaptor
      • 1x IR Remote Commander Unit
      • 1x Ceiling bracket
      • 1x Wire rope
      • 9x Screw M3 x 8
      • 1x Screw M2.6 x 6 BLACK
      • 1x HDMI cable fixing plate
      • 1x Safety regulation
      • 1x Download site information
      • 1x Warranty Information

    • Warranty:

      • 5 Year Limited Warranty
