StarTech MSTCDP123HD USB-C to 3-HDMI Multi-Monitor Adapter Hub

ITEM #: ST-MSTCDP123HD MFG #: MSTCDP123HD

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$72.99

Our Price:

$72.41

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


MSTCDP123HD - Overview

The MSTCDP123HD MST (Multi-Stream Transport) hub lets you connect three HDMI monitors to your USB-C™ computer. MST ensures hassle-free setup by natively working on any Windows® device that supports DP Alt Mode over USB Type-C™, such as models of Dell™ Precision™ and Dell XPS™ laptops and ASUS® ROG GL752.

Increase your productivity with multiple monitors
The newest generation of laptops are more portable than ever. Unfortunately, this means you’re left with fewer video outputs and a small integrated screen. This MST hub solves these problems by letting you connect three displays to a single USB-C port on your computer, which makes multitasking much easier.

Using the MST hub, you can extend your desktop onto additional monitors and stream independent content to each display. This makes it easier to multitask and increase your productivity, which is perfect for creating an easy-to-dock hot-desk solution with a wireless keyboard and mouse peripheral set.

You can also mirror the same image onto multiple displays for remote viewing applications such as digital signage.

Astonishing picture quality that won’t drain your system resources
MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. 4K is supported by the latest A/V devices and delivers four times the resolution of 1080p. Plus, because the MST hub can output high-definition 1080p, the MST hub is perfect for high-resolution applications such as graphic design and medical imaging.

The MSTCDP123HD is backed by a 2-year StarTech.com warranty and free lifetime technical support

  • Features:

    • Maximize your productivity by connecting three independent displays to your computer using the MST hub
    • Hassle-free connection with the reversible USB-C connector
    • Increase external video performance with support for resolutions up to 4K on two monitors simultaneously
    • Thunderbolt 3 port compatible.

  • Specifications:

    • Hardware
    • Audio: Yes
    • Chipset ID: MegaChips - STDP4320
    • VIA/VLI - VL100
    • Converter Type: MST Hub
    • Output Signal: HDMI
    • Ports: 3
    • Maximum Digital Resolutions: 3840 x 2160 @30hz
    • Supported Resolutions: 1024x768; 1280x720 (High-definition 720p); 1920x1080 (High-definition 1080p); 1920x1200; 2560x1440; 2560x1600; 3840 x 2160 (Ultra HD 4K) @30hz
    • Wide Screen Supported: Yes
    • Connector A: 1 - USB-C (24 pin) DisplayPort Alt Mode Male Input
    • Connector B: 3 - HDMI (19 pin) Female Output

      Physical Characteristics
    • Accent Color: Black
    • Cable Length: 11.8 in [300 mm]
    • Color: Black
    • Enclosure Type: Plastic
    • Product Height: 0.6 in [15 mm]
    • Product Length: 4.1 in [105 mm]
    • Product Weight: 4.2 oz [118 g]
    • Product Width: 2.6 in [65 mm]
    • Software:
    • OS Compatibility: Windows 10 (32/64); Windows 8/8.1 (32/64); Windows 7(32/64)
    • Humidity: 50-90%
    • Operating Temperature: 0°C to 45°C (32°F to 113°F)
    • Storage Temperature: -20°C to 70°C (-4°F to 158°F)

  • Warranty:

    • 2 Year

  • GTIN:

    0065030867276
