FG-002074-R001 - Overview

NewTek Connect Spark™ Pro
A portable, production-ready IP video solution that converts supported HDMI 2.0 video signals up to 4K UHD p60 to full-bandwidth NDI® for use with compatible systems, devices, and applications connected to the same Ethernet network. Capture 4K UHD video from any compatible camera or device, and bring it directly into your IP-based production workflow from anywhere on your network with Connect Spark™ Pro-the 4K NDI® video converter from NewTek.

About NewTek NDI
NDI is in use on millions of systems and allows multiple video systems to identify and communicate with one another over IP, and to encode, transmit and receive many streams of high quality, low latency, frame-accurate video and audio in real time. This benefits any network-connected video device, including video mixers, graphics systems, capture cards, and many other production devices. This makes it possible to exponentially increase the number of sources available for live production switching, without directly attaching to devices, changing locations, or investing in expensive, high-bandwidth networks that simply replace SDI-based workflows.

  • Features:

    • HDMI 2.0 video input with embedded audio
    • Conversion to full-bandwidth NDI® for high-quality output to IP with near-zero latency
    • Support for 4K UHD and 1080p video at up to 60 frames per second
    • Optional multicast mode to accommodate network bandwidth considerations
    • Remote configuration & monitoring via Web-based user interface
    • Tally support via NDI®, with built-in program/preview tally lights
    • Wired Ethernet connectivity, with support for Power over Ethernet (POE)
    • Hardware-based FPGA and SoC technology
    • Industry-standard, threaded-screw camera mount
    • Compatible with all systems, devices, and applications that support NDI®


  • Specifications:

    • Video Input: 1 x HDMI 2.0
    • Audio Input: 1 x HDMI embedded audio input (48/44.1/32 KHz); 1 x 1/4" (6.35 mm) Line Level (48 KHz); Stereo audio (2-channel LPCM)
    • Encoding: NDI®
    • Networking: 1 x RJ-45 port for Gigabit Ethernet networking
    • Interface: Web-based user interface for configuration and monitoring
    • Tally: Tally support via NDI® or 1/8" audio jack; Built-in program/preview tally lights
    • Formats: 2160p: 60, 59.94, 50; 1080p: 60, 59.94, 50, 30, 29.97, 25, 24; 720p: 60, 59.94, 50, 29.97, 25, 24; 576p: 50 (16:9, 4:3); 480p: 60, 59.94 (16:9, 4:3)
    • Power: Power over Ethernet (POE); External power via USB type-C (5V 2A)
    • Operating temperature: -20°C to 80°C
    • Relative humidity: 20% to 90%
    • Housing: Portable enclosure with threaded screw camera mount
    • DImensions: 5.37 x 3.32 x .92 in (136.40 x 84.33 x 23.37 mm)
    • Weight: 0.65 lbs (.28 kg)
