tvONE CORIOview C2-6104A 4-Window DVI-U Processor

ITEM #: TV1-C26104 MFG #: C2-6104A

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
tvONE
Free Shipping with $49 Minimum Order

Our Price:

$4,975.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.
Report Lower PriceLarge Quantity Quote

C2-6104A - Overview

The tvONE C2-6104A is a CORIO®2 powered 4-window multi-window processor capable of displaying up to 4 different windows on a single screen. Each video window is capable of being sized, keyed, and layered to meet all viewing requirements.

Customized presentation is made easy with color borders and labels available on each of the 4 video windows along with an additional input for backgrounds and cascades, allowing for all 4 inputs to be used productively without sacrifice. Additionally, 4 still image stores are available and up to 50 preset views can be created and saved for later recall.

The C2-6104-A supports resolution up to 1920x1200@60Hz and HDMI and Universal DVI (DVI-I, DVI-D, and DVI-A) connections. The device also features pixel by pixel scaling, for those times when you just must fit the size exactly the way you need it to.

Applications:
Control Room
Conference Room
Medical
Classrooms

  • Features:

    • 4-Window Processor
    • 4x High Quality CORIO®2 Scaling Engines
    • 5x DVI-U inputs (DVI-I, DVI-A, Composite and S-Video)
    • 5th input for background or cascading multiple units
    • Fully HDCP Compliant
    • 4x Internal Still Image Stores
    • DVI-D I/O support to 1920x1200,1080p@60Hz
    • DVI-A I/O support to 2048x2048, 1080p@60Hz
    • Analog supports RGBHV, RGBS, RGsB, YPbPr
    • 10 User-definable Presets for quick setup
    • Motion Adaptive De-interlacing and Noise Reduction for YUV and YPbPr inputs
    • Color Borders and Source Labeling
    • Variable Image Zoom to 10X and Shrink to 10%
    • Per-pixel or Percentage Scaling Control
    • Autoset - Automatic Analog Picture Sizing
    • Chromakey, Lumakey, Genlock and Mix
    • Front Panel includes LCD, Menu Control and Quick- Setup features
    • Control via RS-232/RS-422/RS-485, Ethernet or Front Panel
    • CORIO Tool Suite compatible
    • Optional modules (e.g. for Tally input/output)
    • 1RU rack-mount case
    • Optional Tally Module


  • Specifications:

    • Inputs
    • Universal DVI 5x DVI-U (DVI-I + YC/CV) HDMI Compatable and fully HDCP Compliant
    • Digital DVI-D Format:
      Max HD Resolution: 1080p@60Hz
      Max PC Resolution: 1920x1200@60Hz
    • Analog DVI-A Format:
      Television Standards: NTSC, PAL, PAL-M, PAL-N, SECAM
      Max HDTV Resolution: 1080p@60Hz
      Max PC Resolution: 2048x2048

      Output
    • DVI-I 1x DVI-I Connector (HDMI Compatable)
    • Digital DVI-D Format:
      Max HD Resolution: 1080p@60Hz
      Max PC Resolution: 1920x1200@60Hz
    • Analog DVI-A Format:
      Television Standards: NTSC, PAL, PAL-M, PAL-N, SECAM
      Max HDTV Resolution: 1080p@60Hz
      Max PC Resolution: 2048x2048

      Control Methods
    • Front Panel Buttons & LCD: RS-232/RS-485/RS-422
    • Ethernet (TCP/IP): RJ45

      Mechanical
    • Desktop Case (HxWxD): 1.75 x 17 x 7.9" (44 x 420 x 200mm)
    • Weight (Net): 6.79Lbs (3.08kg)


  • Warranty:

    • Limited 5 Years Parts and Labor
