Universal Audio APX16-HE Apollo x16 Heritage Edition Thunderbolt 3 Audio Interface (Rack/Mac/Win)

ITEM #: UA-APX16-HE MFG #: APX16-HE

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$4,999.00

Our Price:

$3,999.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


APX16-HE - Overview

Experience the gold-standard in pro audio recording.
Our flagship Apollo x16 gives professional studios and music producers the same iconic analog tones heard on your favorite records. With 16 channels of elite-class A/D and D/A conversion - featuring the widest dynamic range of any integrated audio interface on the market - Apollo x16 seamlessly connects to your outboard analog gear or mixing console, giving your studio the perfect centerpiece in a sleek rackmount Thunderbolt 3 audio interface.

Hear Every Detail in your Recordings
Apollo x16’s proven A/D and D/A conversion gives you the same elite-class sound heard on thousands of hit songs and chart-topping albums. Widely praised for its open, natural sonics, Apollo's converters give you the perfect palette to paint your masterpiece.

The Universal Audio Apollo Heritage Editions deliver a premium software suite of 5 or 10 award-winning UAD plug-in titles - including the full Collections from Teletronix,® Fairchild,® Pultec,® Helios,® and UA - conveniently packaged at significant savings.

These are the same UAD plug-ins that built UA’s reputation for analog modeling over the past decade - including vintage compressors, EQs, mic preamps, and reverb - giving you the most accurate library of classic analog emulations anywhere, right out of the box.

Plug-Ins Included: (Rack)
Helios Type 69 Preamp & EQ Collection
V76 Preamplifier
Oxide Tape Recorder
Teletronix LA-3A Audio Leveler
Fairchild Tube Limiter Collection
Teletronix LA-2A Classic Leveler Collection
Pultec Passice EQ Collection
1176 Classic Limiter Collection
Pure Plate Reverb
UA 610 Tube Preamp & EQ Collection

  • Features:

    • Get professional sound with the widest dynamic range and lowest noise available
    • Mix with powerful HEXA Core processing for running more UAD Powered Plug-Ins with near-zero latency
    • Link up to four Apollos for 156 channels of premium I/O and control it from Apollo Twin or x4
    • Easily connect to professional studio gear with 16 x 16 analog I/O via DB-25 connections, plus switchable +24 dBu headroom settings

  • Specifications:

    • I/O Complement
    • Analog Line Inputs: 16
    • Analog Line Outputs: 16 (not including monitor outputs)
    • Analog Monitor Outputs: Two (one stereo pair)
    • AES/EBU: One stereo input, one stereo output
    • Thunderbolt 2 ports: Two (Thunderbolt 1 compatible)
    • Word Clock: One input, one output

      Electrical
    • Power Supply: External AC to DC Power Supply, Level V compliant
    • AC Input Connector Type: IEC Male
    • AC Requirements: 100V – 240V AC, 50 – 60 Hz
    • DC Connector Type: XLR 4-Pin Locking Male (Neutrik P/N NC4MDM3-H)
    • DC Requirements: 12 VDC, ±5%
    • Maximum Power Consumption: 50 Watts

      Mechanical
    • Dimensions
      Width: 19"
      Height: 1.75" (1U rack space)
      Depth, Chassis Only: 12.125"
      Depth, Including Knob & Jack Protrusions: 13.5"
      Shipping Box (WxDxH): 24 x 17 x 8"
    • Weight
      Shipping Weight (with box & accessories): 18 pounds
      Weight (bare unit): 8.7 pounds

  • Item Includes:

    • 1x Apollo 16 MkII Audio Interface Unit (Heritage Plug-ins)
    • 1x External Power Supply
    • 1x AC Power Cable (IEC)
    • 1x Getting Started URL Card
    • 1x Set of (4) Rack-Mount Screws

  • GTIN:

    0819937003080
