Universal Audio APX4-HE Apollo x4 Heritage Edition 12x18 Thunderbolt 3 Audio Interface (Desktop/Mac/Win)

Name: Universal Audio APX4-HE Apollo x4 Heritage Edition 12x18 Thunderbolt 3 Audio Interface (Desktop/Mac/Win)
Brand: Universal Audio
SKU: UA-APX4-HE
Price: 1999.00 USD
Availability: PreSale

ITEM #: UA-APX4-HE MFG #: APX4-HE

Universal Audio

List Price:

$2,499.00

Our Price:

$1,999.00

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

APX4-HE - Overview

Produce bigger pro sessions from your desktop, in realtime.
Apollo x4 gives engineers and producers recording larger projects the same professional analog tones heard on your favorite records with four onboard Unison™ mic preamps. With elite-class conversion and QUAD Core UAD plug-in processing, Apollo x4 lets you record through preamps from Neve, API, Manley, SSL, and more - with near-zero latency - giving you a fully-stocked analog studio, right on your desktop.

The new Apollo Heritage Editions deliver a premium software suite of 5 or 10 award-winning UAD plug-in titles - including the full Collections from Teletronix,® Fairchild,® Pultec,® Helios,® and UA - conveniently packaged at significant savings.

These are the same UAD plug-ins that built UA’s reputation for analog modeling over the past decade - including vintage compressors, EQs, mic preamps, and reverb - giving you the most accurate library of classic analog emulations anywhere, right out of the box.

Plug-Ins Included:
Helios Type 69 Preamp & EQ Collection
V76 Preamplifier
Oxide Tape Recorder
Teletronix LA-3A Audio Leveler
Fairchild Tube Limiter Collection
Teletronix LA-2A Classic Leveler Collection
Pultec Passice EQ Collection
1176 Classic Limiter Collection
Pure Plate Reverb
UA 610 Tube Preamp & EQ Collection

Features:
- Experience elite-class Apollo sound - as heard on hundreds of hit records
- Record your vocals and synths in realtime through classic mic preamp emulations from Neve, API, Manley, Avalon, and more
- Link up to four Apollos for 156 channels of premium I/O and control it from your Apollo x4
- Create with seamless hardware-software integration and analog console modeling in LUNA Recording System
Specifications:
- I/O Complement
- Microphone Inputs: Four
- High Impedance (Hi-Z) Instrument Inputs: Two
- Analog Line Inputs: Four
- Analog Line Outputs (DC coupled): Four (six including Monitor outputs)
- Analog Monitor Outputs (DC coupled): Two (one stereo pair)
- Headphone Output: Two stereo
- Digital Input Port: One (ADAT or S/PDIF, selectable)
- Digital Output Port: One (ADAT or S/PDIF, selectable)
- Thunderbolt 3 Port: One

  A/D - D/A Conversion
- Simultaneous A/D conversion: Four channels
- Simultaneous D/A conversion: Ten channels
- Supported Sample Rates (kHz): 44.1, 48, 88.2, 96, 176.4, 192
- Bit Depth Per Sample: 24
- Analog Round-Trip Latency: 1.1 milliseconds @ 96 kHz sample rate
- Analog Round-Trip Latency through four UAD legacy plug-ins (included) via Console software: 1.1 milliseconds @ 96 kHz sample rate (no additional latency via Realtime UAD Processing)

  Electrical
- Power Supply: External AC-to-DC Power Supply, Level VI compliant
- AC Input Connector Type: IEC C8, non-polarized
- AC Requirements: 100V - 240V AC, 50 - 60 Hz
- DC Connector Type: Male plug, 2.1 mm x 5.5 mm, center positive
- DC Requirements: 12 VDC, ±5%
- Maximum Power Consumption: 19 Watts (when portable host computer not charging)

  Mechanical
- Temperature Range: 32° to 104°F (0° to 40°C)
- Dimensions:
- Width: 9.17" (23.30cm)
  Height: 2.60" (6.60cm)
  Depth, Chassis Only: 5.95" (15.11cm)
  Depth, Including Knob & Jack Protrusions: 6.17" (15.67cm)
  Shipping Box (LxWxH) 10.75 x 8.11 x 4.9" (27.3 x 20.6 x 12.5cm)
- Weight:
  Shipping Weight (with box & accessories): 3.5Lbs (1.59kg)
  Weight (bare unit): 3.2Lbs (1.46kg)
Item Includes:
- 1x Apollo x4 Unit
- 1x External Power Supply
- 1x AC Power Cable (IEC C7, non-polarized) Region Specific (USA, EU, UK, ANZ, or Japan)
- 1x Getting Started URL Card
GTIN:
0819937003097

APX4-HE - Recommended Accessories

Sescom Mic Cable Canare Star-Quad 3-Pin XLR Male to 3-Pin XLR Female - Black - 15 Foot
SC15XXJ
Our Price: $21.95
Sescom Pro Audio Hum Eliminator Inline with Isolation
IL-19
Our Price: $50.49
Sony Pro MDR-7506 Foldable Large Diaphragm Headphones
MDR-7506
Our Price: $99.99
Sescom Audio Cable Canare Star-Quad 1/4 TRS Balanced Male to 1/4 TRS Balanced Male - Black - 6 Foot
SC6SZSZ
Our Price: $23.49
StarTech TBLT34MM50CM 0.5m Thunderbolt 3 USB-C Cable - 40Gbps
ST-TBLT34MM50CM
Our Price: $32.71
Tripp Lite A102-01M Toslink Digital Optical SPDIF Audio Cable - 3 Feet
TRL-A102-01M
Our Price: $7.00
Yamaha HS5 70 Watt 2-Way Bi-Amp Powered Nearfield Studio Monitor - Each - Black
YMH-HS5
Our Price: $199.99
Shure SM7B Dynamic Cardioid Vocal Microphone
SH-SM7B
After Savings: $359.00
Furman SS-6B 6-Outlet Surge Suppressor Strip
FUR-SS6B
Our Price: $39.99
