Vaddio OneLINK HDMI Extension for HDBaseT Conference Cameras - Video and Power Extender

999-1105-043 - Overview

• Features:

  • MADE IN THE USA!
  • Simple, clutter-free camera extension with HDBaseT technology
  • Power, video and control over a single Cat-5e cable up to 230 ft. (70m), or over a Cat-6 cable up to 328 ft. (100m)
  • More flexibility in camera placement
  • HDBaseT interface extends power, video and control up to 328 ft (100 m)
  • Plug and play usability
  • Intuitive browser-based user interface for configuration and system administration


• Specifications:

  • Color: Black
  • Certifications: CE Approved, FCC Approved, UL Listed, TAA Compliant
  • Product Width: 8.38" (21.29 cm)
  • Product Height: 1.72" (4.37 cm)
  • Product Depth: 6" (15.24 cm)
  • Product Weight: 1.55 lbs (0.7 kg)
  • Power Type: Local Power
  • Input Ports: HDbT
  • Output Ports: HDMI
  • Browser-based User Interface for Remote Control: Built-in
  • Control Method: Telnet
  • OneLINK Compatibility: Native
  • Operating Temperature: 32° to 104°F (0° to 40°C)
  • Warranty: 2 years
  • Power Supply: 12 VDC, 3.0 A
  • Quick-Connect Compatibility: No
  • Distance: 328 ft (100 m)


• Item Includes:

  • OneLINK HDMI Interface
  • Quick-Start Guide
  • 48V power supply with AC cord set(s)
  • EZCamera RS-232 Control Adapter


• GTIN:

  0840077500832
