Vaddio 999-9950-000B RoboShot 20 UHD HD-SDI 4K Streaming PTZ Camera -20x Zoom - Black

ITEM #: VAD-999-9950-000 MFG #: 999-9950-000

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Our Price:

$6,388.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


999-9950-000 - Overview

The Vaddio RoboSHOT 20 UHD Camera is an Ultra HD (4K) PTZ camera with pristine color reproduction, outstanding low light performance, and unrivaled video performance. With enterprise class features including IP streaming and network control via web interface, this camera is designed for use in UHD or HD environments such as higher education, corporate broadcast and houses of worship.

The camera optics feature a 12x optical zoom lens with seamless transition to 1.67x digital zoom, for a total zoom range of 20x. The camera uses a 1/2.3-type, high-speed, low noise, back illuminated CMOS sensor with 9.03 total megapixels, producing native 2160p/30 (3840 x 2160) video images without scaling.

With a 74-degree wide horizontal field-of-view and built in CCU with browser configuration, the RoboSHOT 20 UHD provides great flexibility in a variety of applications including video production, live events, lecture capture, or conferencing.

  • Features:

    • MADE IN THE USA!
    • Back-illuminated 9.03 Megapixel, ultra high definition 1/2.3-type sensor delivers native 2160p/30 (3840 x 2160) video
    • Horizontal field of view 74° (wide) to 4.8° (tele) at 20x
    • Imaging and performance comparable to 3-chip cameras
    • Precise pan and tilt movements from 0.35° to 120° per second
    • Simultaneous HDMI, HDBT, HD-SDI and IP streaming outputs
    • Presenter-friendly IR remote control
    • Administrative control via web interface

  • Specifications:

    • Video and Image
    • Outputs/protocols HDMI, HDBT, HD-SDI, IP (H.264)
    • Aspect ratio: HDMI: 16:9 (all resolutions), IP (H.264) Streaming: 16:9, 3:2 and 4:3
    • HDMI resolutions/frame rates: QFHD: 2160p/30/25 (3840 x 2160) FHD: 1080p/59.94/50/29.97/25, 1080i/59.94/50, HD: 720p/59.94/50
    • 3Gb/s HD-SDI resolutions/frame rates: FHD: 1080p/59.94/50/29.97/25, 1080i/59.94/50, HD: 720p/59.94/50
    • Streaming: Simultaneous IP (RTSP format with H.264 compression) up to 1080p/30
      Camera
    • Image device: 1/2.3-Type Exmor R High-speed, Low-noise CMOS Sensor
    • Pixels: 9.03 Megapixels Total, 8.93 Effective Megapixels
    • Zoom: 12X optical zoom, 1.67X digital zoom; combined total 20X zoom
    • Minimum illumination: 3.0 lx (F1.8, 50IRE) color; recommended 100+ lux
    • Horizontal FOV 74° (wide) to 4.8° (tele)
    • Min. working distance: 10 mm (wide), 1500 mm (tele)
    • Pan angle and speed: ±160°, 0.35°/sec to 120°/sec
    • Tilt angle and speed: +90, -30°, 0.35°/sec to 120°/sec
    • Gain: Auto / Manual (0 to 33 dB)
    • Aperture/detail: 16 Steps
    • Focusing system: Auto Focus / Manual Focus Mode / One Push Trigger Mode
    • White balance: Auto, ATW, Indoor, Outdoor, One-push, Manual
    • Backlight compensation: On/off
    • Sync system: Internal
    • Noise reduction: 6 steps
    • S/N ratio: Over 50 dB
    • Control and management: Vaddio IR Remote Commander, web interface (Chrome, Firefox, Safari, Internet Explorer, Microsoft Edge), Telnet, RS-232 API (modified VISCA)
    • Power: 12 VDC, 3.0 Amp power supply; LTPoE++
      Physical and Environmental
    • Height 7.9 in
    • Width 8.0 in
    • Depth 7.7 in
    • Weight 6 lbs
      Operating temperatute: 23°F to 140°F
    • Operating humidity: 20% to 80% RH (non-condensing)
    • Storage temperature: -4°F to 140°F
    • Storage humidity: 20% to 95% RH

  • Item Includes:

    • RoboSHOT 20 UHD camera, 998-9950-000
    • 12 VDC, 3.0 A switching power supply with AC cord set(s)
    • Thin Profile Wall Mount with mounting hardware, black (535-2000-240) or white (535-2000-240W), depending on camera color
    • Vaddio IR Remote Commander (998-2100-000)
    • EZCamera RS-232 Control Adapter (998-1001-232)
    • Quick Start Guide

  • GTIN:

    0840077503758
