Theatrixx XVV2FIBER2SDI-M3 xVision Dual Channel Fiber to 3G-SDI - PT1 In/Thru - Multimode - OpticalCON QUAD

ITEM #: XVV2FIBER2SDI-M3 MFG #: XVV2FIBER2SDI-M3

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$1,670.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    XVV2FIBER2SDI-M3 - Overview

    Professional equipment in mission-critical applications is all about reliability and confidence. So we started with a clean sheet, and built what might soon become your most trustworthy piece of equipment.

    Introducing the world's first video converters truly designed for the road. Video converters nowadays are used everywhere on profesionnal A/V events, presentations, live shows and tours and often have a critical role.

    Yet, they are often the weakest link in the signal chain. Low quality connectors, weak enclosure, external consumer-grade power supply, and overall barebones design that all contribute to a generally unreliable piece of equipment. Theatrixx wanted to change that, so we designed the Theatrixx XVV2FIBER2SDI-M3 Dual Channel Fiber to 3G-SDI with OpticalCON QUAD xVision Video Converter.

    • Features:

      • Integrated power supply with locking PowerCON Connector. Never rely on a cluster of wall-warts again
      • Built-in convenience AC outlet to power nearby projector, TV, laptop, small video projector… Power bar to power both the converter and device not required anymore
      • Magnetic stacking system and non-skid rubber pad for table top application. Saves at least 10 gaffer tape rolls a year
      • Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adaptor
      • Rugged, Tour-ready and aesthetic enclosure: The sexiest widget in your tool box, that will keep looking good for years to come
      • Plug-n-play operation; No dipswitches, buttons or menus to fumble with : It just works
      • Clear and ample status LED indicators for quick troubleshooting
      • Easy on-the-field identification with unique color and alphabetic coding system
      • SFP-based video transmission for interoperability with standard SDI over fiber devices
      • Choice of three optical connectors, each available as singlemode and multimode types
      • Reclocked and amplified SDI loop thru
      • Proudly designed and assembled in Canada

    • Specifications:

      • Connections
      • Video Input: 2 x 3G/HD/SD SDI BNC
      • Loop-thru: 2 x 3G/HD/SD SDI BNC
      • Video Ouput: Multimode - OpticalCON QUAD

        Supported Signals
      • Video Format: 3G-SDI Level A and B, HD-SDI, SD-SDI with embedded audio
      • SMPTE Standards: 2082-1, 2082-10, 425 M Level A & B, 424 M, 292 M, 259 M

        Physical
      • Height: 62 mm (2.44 in)
      • Depth: 180 mm (7.08 in)
      • Width: 221 mm (8.7 in)
      • Weight: 2 kg (4.4 lbs)
      • Alternate Form Factor: Also available as a Reversible Module

        Environmental
      • Relative Humidity: 0% to 90% non-condensing
      • Operating Temperature: 0-40 °C

        Power Requirements
      • Power Supply: Built-in power supply - PowerCon True1 input, PowerCON True1 output (loop-thru)
      • Power Consumption: 45W max.
      • Operational Voltage Range: 100-240V, 50-60Hz
      • Courtesy Outlet: Max 10 A, same voltage as input

    • Item Includes:

      • 1x XVV2FIBER2SDI-M3 xVision Dual Channel Fiber to 3G-SDI - PT1 In/Thru - Multimode - OpticalCON QUAD
      • 1x Edison (5-15) to PowerCON True1 Cable (1.5m)
      • 1x 25mm X 65cm Fabric Strap
      • 1x M10 X 20mm Flat Screw + 1x M10 X 30mm Socket Cap Screw
