Theatrixx 3G-SDI to Fiber Video Converter - PWCA In/Edison Thru - MM - OpticalCON Duo

ITEM #: XVVSDI2FIBER-M2 MFG #: XVVSDI2FIBER-M2

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$840.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


XVVSDI2FIBER-M2 - Overview

Introducing the world's first video converters truly designed for the road. Video converters nowadays are used everywhere on profesionnal A/V events, presentations, live shows and tours and often have a critical role.

Yet, they are often the weakest link in the signal chain. Low quality connectors, weak enclosure, external consumer-grade power supply, and overall barebones design that all contribute to a generally unreliable piece of equipment. To change that, Theatrixx designed the xVision Video Converters.

  • Features:

    • Integrated power supply with locking PowerCON Connector. Never rely on a cluster of wall-warts again.
    • Built-in convenience AC outlet to power nearby projector, TV, laptop, small video projector... Power bar to power both the converter and device not required anymore.
    • Magnetic stacking system and non-skid rubber pad for table top application. Saves at least 10 gaffer tape rolls a year.
    • Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adaptor.
    • Rugged, Tour-ready and aesthetic enclosure: The sexiest widget in your tool box, that will keep looking good for years to come.
    • Plug-n-play operation; No dipswitches, buttons or menus to fumble with: It just works.
    • Clear and ample status LED indicators for quick troubleshooting.
    • Easy on-the-field identification with unique color and alphabetic coding system.
    • SFP-based video transmission for interoperability with standard SDI over fiber devices.
    • Reclocked and amplified SDI loop thru.

  • Specifications:

    • Connections:
    • Video Input: 1 x 3G/HD/SD SDI BNC
    • Loop-thru: 1 x 3G/HD/SD SDI BNC
    • Video Output: Multimode, OpticalCON DUO

      Supported Signals:
    • Video Format: 3G-SDI Level A and B, HD-SDI, SD-SDI with embedded audio
    • SMPTE Standards: 425 M Level A & B, 424 M, 292 M, 259 M

      Physical:
    • Height: 50 mm (1.97 in)
    • Depth: 180 mm (7.08 in)
    • Width: 107 mm (4.21 in)
    • Weight: 1 kg (2.2 lbs)
    • Alternate Form Factor: Also available as a Reversible Module

      Environmental:
    • Relative Humidity: 0% to 90% non-condensing
    • Operating Temperature: 0-40 °C

      Power Requirements:
    • Power Supply: Built-in power supply, PowerCON input, Edison Nema 5-15 output (loop-thru)
    • Power Consumption: 15W
    • Operational Voltage Range: 100-120V, 50-60Hz (100-240V, 50-60Hz available with PowerCON True1)
    • Courtesy Outlet: Max 10A, same voltage as input

  • Item Includes:

    • 1x xVision Converter SDI to Fiber
    • 1x AC Mains to PowerCON cable
