Anton Bauer 8475-0143 VM2 Dual V-Mount Charger

ITEM #: AB-8475-0143 MFG #: 8475-0143

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$322.00

Our Price:

$289.80

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


8475-0143 - Overview

Antony Bauer 8475-0143VM2 Dual V-Mount Battery Charger
Intelligent charging with power to spare. Charge two V-Mount batteries simultaneously while powering your camera accessories with the lightweight and portable Antony Bauer VM2 battery charger. Lithium-ion batteries, like the Antony Bauer GO 90 (98Wh 10A) charge in approximately 3 hours. The XLR4 output converts AC to DC power when charging or can be used to deliver battery power to devices that only have an XLR input.

Lightweight, compact dual battery charger. The portable, packable charging solution
A power-up wherever you need it. With two V-Mount battery mounts and an XLR4 DC output the Antony Bauer VM2 charger is the ideal solution for roaming imagemakers. Simply connect to AC power and pop the integrated support stand to create a quick-to-set-up plug and play charging station for V-mount batteries, and a 15VDC 4A convertor for XLR power input devices. The slim profile is designed to stack and pack, perfect for transportation when space matters.

Advanced safety monitoring - Protection your batteries and devices
Stays cool in the heat of the action. VM2 chargers are designed to protect your batteries and any powered devices from damage. Intelligent safety technology in the VM2 constantly monitors all devices and will automatically stop charging if a fault is detected or any attached battery reaches an overvoltage condition. A built-in fan ensures that the charger can be relied on for peak performance when things start heating up on set.

  • Features:

    • Charge two V-Mount batteries simultaneously
    • 100-240 VAC input
    • XLR4 15 VDC / 4A power output
    • Use charger and XLR output at the same time
    • Portable design with carry handle
    • Integrated support stand
    • LEDs show battery charging status

  • Specifications:

    • Mount: V-Mount
    • Battery Bays: 2
    • Output Connector: 4-Pin XLR Female
    • AC Input Power: 100 to 240 VAC, 50 / 60 Hz at 1.5 A
    • Output Voltage (via AC power): 16.7 VDC at 4.5 A (4-Pin XLR Female)
    • Output Voltage (via battery / batteries): 15 VDC at 4 A (4-Pin XLR Female)
    • Multi-Bay Charging Modes: Simultaneous
    • Max. Wattage: 75W
    • Operating Temp: 14 to 95°F / -10 to 35°C
    • Indicator: LED
    • Dimensions (HxWxD): 9.25" x 2.25" x 5.5" / 23.5 x 5.7 x 14 cm
    • Weight: 2.2 lbs. / 1 kg

  • Item Includes:

    • 1x Anton/Bauer Dual V-Mount Charger
    • 1x 4 Pin XLR Cable (Length ~10 ft. / 3 meters)

  • GTIN:

    5060520687094
