ADDERLink X100A/R-US X100 Receiver for CATx - Audio - VGA - PS/2

X100A/R-US - Overview

• Features:

  • Video performance: Industry leading resolutions of 1600 x 1200 are achievable up to 100m (330ft), 1900 x 1440 up to 50m (165ft).
  • Video compensation: The ADDERLink X-100 applies signal compensation that allows for smooth and fine adjustments providing great video quality up to 100m.
  • Emulated DDC: Unless an extender actively supports DDC some wellknown high performance video cards cannot be used at high resolutions. The ADDERLink X-100s fully support DDC.
  • USB Emulation: When using an X-100 pair to extend a CPU with a USB keyboard and mouse interface, it is ensured that the keyboard and mouse are continually emulated for maximum availability and essential functionality such as country code reporting for Sun CPUs.
  • Brightness control: The ADDERLink X-100s offer their own brightness correction to ensure images are crisp, clear and bright.
  • Audio: Optional digital stereo audio delivers high fidelity audio for speakers.
  • Variety of models available: To suit the maximum possible number of applications the X-100 is available in a number of models, PS/2 and video (X-100-PS2/P) PS/2, video and audio (X-100A-PS2/P), USB and video (X-100-USB/P) and USB, video and audio (X-100A-USB/P).


• Specifications:

  • Video resolutions
  • 1600 x 1200 at distances up to 100m/330ft,1900 x 1440 at distances up to 50m/165ft


  • Extension distance
  • Up to 100m/330ft using CATx cable (x=5,5e,6,7)


  • Devices supported
  • Supports any computer with PS/2 or USB style keyboard and mice, flat-screen and CRT style monitors with standard HD-15 video connectors and optional audio through 3.5mm audio jack


  • O/S compatibility
  • All known software and operating systems including Windows (all), DOS, Linux, Unix, BSD, Sun OS, Solaris, Mac OS, NetWare etc.


  • Connectors (local)
  • Video: HDD15
  • Keyboard Mouse: MiniDin6.
  • Optional audio: 3.5mm jack
  • CATx: 1 x RJ45 connector
  • Or
  • Video: HDD15
  • Keyboard Mouse: USB type A.
  • Optional audio: 3.5mm jack
  • CATx: 1 x RJ45 connector


  • Connectors (remote)
  • Video: HDD15
  • Keyboard Mouse: MiniDin6.
  • Optional audio: 3.5mm jack
  • CATx: 1 x RJ45 connector.
  • Power: 2.5mm DC jack


  • Physical (local)
  • Combination of plastic enclosure and cables.
  • Enclosure: 64mm x 45mm x 25mm
  • Cables: 340mm long


  • Physical (remote)
  • All metal case, 123mm x 74mm x 26 mm


  • Power supply
  • 100 - 240VAC 50/60Hz


  • Operating temperature
  • 0 - 40 deg C (32 to 104 deg F)


  • Approvals
  • CE, FCC


• Item Includes:

  • 1x Audio-equipped X100 module with PS/2-style CAM
  • 1x Power adapter with US cord


• Warranty:

  • 2 Year Limited


• GTIN:

  0997252247454
