AVMATRIX SC1112-12G 12G-SDI to HDMI 2.0 4K60 Broadcast Converter

ITEM #: AVMX-SC1112-12G MFG #: SC1112-12G

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
AVMATRIX
Free Shipping with $49 Minimum Order

List Price:

$219.00

Our Price:

$199.00

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

SC1112-12G - Overview

Effortlessly Converting in 4K Broadcast Quality, Bringing Every Frame to Life with Unmatched Clarity

The compact AVMATRIX SC1112-12G converter provides 12G-SDI and 4K HDMI interfaces, supporting HD/3G/6G/12G-SDI input formats. It enables direct conversion with unparalleled latency, making it the perfect choice for broadcast applications demanding uninterrupted, high-performance signal transmission.

12G-SDI In and Loop-Out
The converter has a 12G-SDI loop-out that can transmit the SDI video to an additional display directly. It allows users to output to two screen simultaneously for monitoring.

4K@60 Resolution Support
The converter features advanced auto-detection technology, seemlessly matching you SDI input to the HDMI output. It supports a wide range of input and output resolutions, including crystal-clear 4K@60 (4096*2160).

  • Features:

    • 12G-SDI TO HDMI2.0
    • 12G-SDI Loop-out
    • Up to 4K60 resolution
    • USB Type-C Power
    • SDl with Equalization and Re-clock
    • Video & power signal LED indicators


  • Specifications:

    • Input/Output
    • SDI Video Input: 1x HD/3G/6G/12G-SDI
    • SDI Video Loop Output: 1x HD/3G/6G/12G-SDI
    • HDMI Video Output: 1x HDMI 2.0

      SDI Formats
    • SDI Input Format:
      - (12G) 4096x2160p 60/59.94/50
      - (12G) 3840x2160p 60/59.94/50
      - (6G) 4096x2160p 30/29.97/25/24/23.98
      - (6G) 3840x2160p 30/29.97/25/24/23.98
      - (3G level-A) 1920x1080p 60/59.94/50
      - (3G level-B) 1920x1080p 60/59.94/50
      - (HD) 1920x1080p 30/29.97/25/24/23.98
      - (HD) 1920x1080i 60/59.94/50
      - (HD) 1920x1080Psf 30/29.97/25/24/23.98
      - (HD) 1280x720p 60/59.94/50/30/29.97/25/24/23.98
    • SDI Video Rate: HD/3G/6G/12G-SDI
    • SDI Compliance: SMPTE ST-2081, SMPTE ST-2082, SMPTE 292M, SMPTE 296M, SMPTE 424M-B, SMPTE 274M, SMPTE 275M
    • SDI Color Space and Precision: YCbCr 4:2:2 10bit
    • SDI Auto Switching: Auto Selects HD/3G/6G/12G-SDI

      HDMI Formats
    • HDMI Output Format:
      - (4K) 4096x2160p 60/59.94/50/30/29.97/25/24/23.98
      - (4K) 3840x2160p 60/59.94/50/30/29.97/25/24/23.98
      - (HD) 1920x1080p 60/59.94/50/30/29.97/25/24/23.98
      - (HD) 1920x1080i 60/59.94/50/48/47.98
      - (HD) 1280x720p 60/59.94/50/30/29.97/25/24/23.98
    • HDMI Color Space and Precision: RGB 8bit, YCbCr 4:2:2 8bit, 10, 12bit, YCbCr 4:4:4 8bit
    • HDMI Compliance: CTA-861-G

      Power
    • Power: USB Type-C
    • Power Consumption: ±4.5W (5V 0.9A)
    • Voltage Range: 5V

      Phsycial
    • Dimensions (LxWxD) 42.36" x 22.83" x 7.48" (107.6mm x 58mm x 19mm)
    • Weight: 0.52lbs (235g)
    • Operating Temperature: 32°F - 140°F (0°C - 60°C)
    • Storage Temperature: -4°F - 158deg;F (-20°C - 70°C)
    • Relative Humidity: 0% - 90% non-condensing


  • Item Includes:

    • 1x AVMATRIX SC1112-12G 12G-SDI to HDMI 2.0 4K Broadcast Converter


  • Warranty:

    • 2 Year Limited Warranty


  • GTIN:

    6950821602818
