AVMATRIX UC1218-4K 4K HDMI to USB 3.1 Type-C Video Capture

ITEM #: AVMX-UC1218-4K MFG #: UC1218-4K

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
AVMATRIX
Free Shipping with $49 Minimum Order

List Price:

$219.00

Our Price:

$199.00

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

UC1218-4K - Overview

The AVMATRIX UC1218-4K is a a broadcast-grade real plug and play device to capture uncompressed HDMI signals over USB3.1 Gen1 for graphics capture, livestreaming and recording on a laptop or PC. The input HDMI resolution supports up to 4K60HZ and has a 4K HDMI loop-out for monitoring every detail of the original 4K source on an additional monitor. Additionally the device has an HDMI output to monitor the captured video from an HD HDMI monitor.

The UC1218-4K is real plug and play, no driver is needed, and it is compatible with systems including Windows, Linux and more. It's also UVC and UAC compliant. It's the ideal choice for live broadcast, streaming, and professional AV workflows including podcasting, web conferencing, video production and screen capture.re.

  • Features:

    • Inputs: 4K HDMI in, Mic/Line in
    • Outputs:4K HDMI loop-out, HDMI out, USB 3.1 Gen1 (USB 3.0) out, audio out
    • Automatic input signal detection, up to 4K60Hz
    • 4K HDMI input with loop-out and downscaled HD HDMI out
    • Uncompressed video & audio capture, comply with UVC and UAC
    • Plug-and-Play, driver free & power free
    • Compatible with Windows, Linux, macOS
    • Compatible with OBS, ZOOM, Teams, Twitch, Vmix, etc


  • Specifications:

    • Connections
    • Video Interface:
      - 1x HDMI 2.0 in
      - 1x HDMI in
      - 1x HDMI 2.0 loopout
      - 1x USB 3.0 TypeC (USB 3.1 Gen1, up to 200MB/s)
    • Audio Interface:
      - 1x 3.5mm stereo audio (Line in)
      - 1x 3.5mm stereo audio (Mic in)
      - 1x 3.5mm stereo audio out

      Format
    • HDMI 2.0 Input & Loop out Format: Up to 4K60hz, 1440p144hz, 1080p240hz
    • USB Capture Format: 1920x1080, 1680x1050, 1440x900, 1280x1024, 1280x960, 1280x800, 1280x720, 1024x768, 800x600, 720x576, 720x480, 640x48060hz
    • Audio & Video Capture: UVC (USB video class) standard, UAC (USB audio class) standard
    • Audio Codec: 2-channel, 16bitPCM, 48kHz, 1536kbps
    • Video Color Space: YUY2
    • Hardware de-interlacing: Support 1080i hardware de-interlacing, clearer and more stable picture

      OS and Software Compatibility
    • Supports OS: Windows 7/8/10, Linux (Kernel version 2.6.38 and above), macOS (10.8 and above)
    • Software Compatibility: OBS studio, Skype, ZOOM, Teams, Google Meet, Youtube Live, QuickTime Player, Facetime, etc. Compatible SDK: DirectShow (Windows), Direct Sound (Windows)

      General
    • Dimensions: 4.09" x 2.97" x 0.75" (104mm x 75.5mm x 19mm)
    • Net Weight: 10.02oz (284g)
    • Gross Weight: 13.47oz (382g)
    • Power Consumption: 4.5W ±10%
    • Operating Temperature: -4°F - 140°F (-20°C - 60°C)
    • Storage Temperature: -22°F - 158°F (-30°C - 70°C)
    • Relative Humidity: 20% - 90% RH (no condensation)


  • Item Includes:

    • 1x AVMATRIX UC1218-4K 4K HDMI to USB 3.1 Type-C Video Capture


  • GTIN:

    6971118002122
