Barix MULTICODER M400 Package - Low-Latency Audio over IP Encoder - AAC+ and OPUS with Latest Security

ITEM #: BARIX-MULTICM400 MFG #: 2023.9435P

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Our Price:

$395.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


2023.9435P - Overview

4 internal encoders - Max 10 streams per encoder

The Barix MULTICODER M400 Package is a low-latency Audio over IP Encoder that can do AAC+ and OPUS with the latest security.

The Barix Multicoder M400 boasts up to four internal encoding engines and is capable of simultaneous operation, each supporting various audio formats. With support for streaming protocols RTP and BRTP, it can achieve exceptionally low latency. This device can encode incoming audio from connected analog sources into formats like OPUS, AAC+. The Multicoder M400 is purpose-built for low-latency applications and leverages a new Linux-based platform to provide robust security features, including HTTPS for the setup of the device.

  • Features:

    • 4 internal encoders
    • Max 10 streams per encoder
    • Line-in mono/stereo (configurable)
    • Generic USB audio driver for support of USB audio sources (e.g. USB Microphone or USB Mixer)
    • Supported audio codecs: OPUS, AAC+, MP3, PCM, G.711
    • Protocols: RTP, BRTP
    • Streaming modes: Send Always, Send on Level
    • Audio inputs: mono left, mono right, stereo, stereo downmix
    • Configurable SSRC
    • HTTP/HTTPS websetup
    • Embedded SDP file creator
    • Supply voltage 5VDC

  • Specifications:

    • Power Supply Input
    • External power adaptor, 100-240VAC, 10W
    • Male Barrel Connector: 5.5mm x 2.1mm

      Ethernet Interfaces
    • RJ45 10/100 auto detect, IPv4, IPv6

      Audio Input
    • Stereo RCA/cinch connectors (also mono configurable)
    • 2kΩ input impedance 3.9 Vpp max, adjustable in sensitivity
    • Dynamic range 87 dB, SNR -87 dB

      Audio Formats
    • OPUS, AAC+ (AAC-HC and AAC-LC)
    • MP3
    • PCM
    • G.711
    • Sample Rates: 8/16/22.05/24/32/44.1/48Khz
    • Supported Bit Rates: 32kb/s to 320 kb/s

      Network Protocols
    • Setup: HTTP/HTTPS
    • Streaming: RTP, BRTP (requested RTP)

    • Headphone Output: Female Jack 3.5 mm
    • USB: 2 extension ports for USB devices (for future use)
    • RS-232: DB-9, currently not in use

      HW/SW Environment
    • Barix IPAM400 Processor Module
    • Linux with dual boot recovery and remote
    • firmware update capability

      User Interface
    • Network interface for control, status and setup
    • HW reset button, LED for status

      Case & Weight
    • Aluminum
    • Dimensions: 4.25" x 1.5" x 3.1" (108mm x 38mm x 78.7mm)
    • Weight: 8.82oz (250g)

      MTBF
    • >199.951h/22 year

  • Item Includes:

    • 1x Barix MULTICODER M400 with US power supply

  • Warranty:

    • 2-Years
