BZBGEAR BG-8K-HS21 2x1 8K UHD Ultra Slim HDMI 2.1 Switcher - 8K60/4K120Hz 4:4:4 10bit

ITEM #: BG-8K-HS21 MFG #: BG-8K-HS21

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$49.00

Availability: In Stock
iAvailability Description Popup


    BG-8K-HS21 - Overview

    The BZBGEAR BG-8K-HS21 8K 2x1 HDMI 2.1 switcher is a versatile device that allows you to switch between two HDMI sources and display the selected input on a single HDMI display. It offers support for high-resolution video up to 8K at 60Hz with 4:4:4 chroma subsampling, providing crisp and detailed images with excellent color accuracy. Additionally, the switcher has a high video bandwidth of 48Gbps, which enables it to handle the large amounts of data required for high-quality 8K video.

    This switcher is an ideal solution for those who want to be able to easily switch between multiple HDMI sources, such as a gaming console, Blu-ray player, or streaming device. Whether you're watching movies, playing games, or simply want to be able to easily access multiple sources of content, the 8K 2x1 HDMI 2.1 switcher can help ensure that you have access to the best possible video quality.

    For gamers, the ability to display high-resolution graphics at high frame rates is crucial for a smooth and immersive gaming experience. With support for 4K resolution at 120Hz, the BG-8K-HS21 can help ensure that your games are displayed with the highest level of detail and fluidity. This is particularly important for fast-paced games where a high frame rate can make a significant difference in your ability to react to in-game events. Whether you're playing competitively or just looking for the most realistic and engaging gaming experience possible, the 8K HDMI 2x1 switcher’s support for 4K at 120Hz can help you get the most out of your favorite games.

    • Features:

      • HDMI 2.1 and HDCP 2.3 compliant
      • Support 48Gbps video bandwidth
      • 8K@60Hz 4:4:4 8/10/12-bit, 8K@60Hz 4:2:0 12-bit, 8K@ 30Hz 4:4:4 10-bit, 4K@120Hz 4:4:4 10-bit video support
      • HDR, HDR10, HDR10+, Dolby Vision, HLG pass through
      • VRR, FVA, ALLM
      • HDMI audio formats: LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio
      • 2x1 manual switch or auto switch capabilities
      • Built-in Equalizer and Driver
      • Auto EDID management
      • Compact design for easy and flexible installation

    • Specifications:

      • Technical
      • HDMI Compliance: HDMI 2.1
      • HDCP Compliance: HDCP 2.3
      • Video Bandwidth: 48Gbps
      • Video Resolution: Up to 8K@60Hz 4:4:4 8/10/12bit, 8K@60Hz 4:2:0 12-bit, 8K@30Hz 4:4:4 10-bit, 4K@120Hz 4:4:4 10-bit
      • Color Depth: 8-bit, 10-bit, 12-bit
      • Color Space: RGB, YCbCr 4:4:4 / 4:2:2 / 4:2:0
      • HDMI Audio Formats: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD

        Connection
      • Input: 2x HDMI IN [Type A, 19-pin female]
      • Output: 1x HDMI OUT [Type A, 19-pin female]

        Mechanical
      • Housing: Plastic Enclosure
      • Silkscreen Color: Black
      • Dimensions: 2.4" (W) x 2.4" (D) x 0.47" (H)
      • Weight: 0.07lbs [31g]
      • Power Supply: USB 5V
      • Power Consumption: 1.25W (Max)
      • Operation Temperature: 32°F ~ 104°F / 0°C ~ 40°C
      • Storage Temperature: -4°F ~ 140°F / -20°C ~ 60°C
      • Relative Humidity: 20~90% RH (non-condensing)

    • Item Includes:

      • 1x 8K Two-Input HDMI Switcher
      • 1x Micro USB Power Cable
      • 1x User Manual
