Belden C602106006 CAT6+ 4-Pair 24 AWG Patchcord CMP - Blue - 6 Foot

ITEM #: BL-C602106006 MFG #: C602106006

Primary Image
Belden
Free Shipping with $49 Minimum Order

List Price:

$18.50

Our Price:

$17.83

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

C602106006 - Overview

Belden C602106006 is a 6 foot 4-air 24AWG CAT6+ Video Patchcord, Bonded-Pair, Solid, CMP, T568A/B-T568A/B. Suitable for IBDN System 4800, IBDN System 3600, IBDN System 2400,TIA Category 6, ISO Class E, and 1000BASE-T applications.

  • Specifications:

    • # Pairs: 4
    • AWG: 24
    • Stranding Conductor: Solid
    • Material: BC - Bare Copper
    • Color: Blue
    • Overall Cabling Fillers: Cross Web
    • Overall Nominal Diameter: 6.045 mm
    • Boot Color: Translucent
    • Weight: 0.100 kg
    • Plug / Jack Compatibility: RJ45
    • Storage Temperature Range: -40°C To +70°C
    • Installation Temperature Range: -10°C To +60°C
    • Operating Temperature Range: -10°C To +60°C
    • Max. Recommended Pull Tension: 111.205 N
    • Min. Bend Radius (Overall Cable): 26.416 mm
    • UL Rating: Plenum
    • Other Standards: FCC Part 68, Subpart F, IEC 60603-7
    • Dielectric Strength: 1,000 V RMS @ 60 Hz for 1 minute
    • Current Rating: 1.500 A
    • Insulation Resistance: 500 M-Ohm Minimum
    • Max. Contact Resistance: 20 m-Ohm


  • Item Includes:

    • 1x Belden C602106006 CAT6+ 4-Pair 24 AWG Video Patchcord CMP - Blue - 6 Foot
