Belden CAF1100033 10GX F/UTP CMR Patch Cord - Black - 33 Feet

ITEM #: BL-CAF1100033 MFG #: CAF1100033

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$61.18

Our Price:

$51.00

Availability: 2+ Weeks.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


CAF1100033 - Overview

Belden CAF1100033 is a 10GX F/UTP CMR Patch Cords best used for IBDN Shielded System 10GX, TIA Category 6A, ISO Class EA, 10GBASE-T applications.

  • Specifications:

    • Total Number of Pairs: 4
    • Overall Nominal Diameter: 0.275 in
    • Wiring Scheme: T568A/B-T568A/B
    • Packaging: Individually packaged in a clear plastic bag.
    • Boot: Lexan Translucent
    • Conductor: BC - Bare Copper
    • Front Connection: Blades Phosphor Bronze with 50u inch Gold over Nickel Plating
    • Inner Jacket: PVC - Polyvinyl Chloride
    • Insulation: PO - Polyolefin
    • Outer Jacket: PVC - Polyvinyl Chloride
    • Dielectric Strength: 1,000 V RMS @ 60 Hz for 1 minute
    • Current Rating: 1.500 A
    • Insulation Resistance: 500 M-Ohm Minimum
    • Max Contact Resistance: 20 mOhm
    • Installation Temp Range: -10°C To +60°C
    • Storage Temp Range: -40°C To +70°C
    • Operating Temp Range: -10°C To +60°C
    • Min Bend Radius (Overall Cable): 2.200 in
    • Plug /Jack Compatibility: RJ45
    • UL Rating: Riser
    • Data Category: Category 6A
    • Telecommunications Standards: Category 6A - TIA 568-C.2, Class EA - ISO/IEC 11801:2002 Ed.2 Amendment 2
    • Other Standards: FCC Part 68, Subpart F, IEC 60603-7
    • Environmental Space: Riser
    • EU Directive 2002/95/EC (RoHS): Yes
    • EU RoHS Compliance Date (yyyy-mm-dd): 2006-01-01
    • MII Order #39 (China RoHS): EUP 50


CAF1100033 - Required Accessories
