Blustream PRO88HDMI-V2 Custom Pro Preconfigured 8x8 HDMI 2.0 4K @ 60Hz 4:4:4 Matrix

PRO88HDMI-V2 - Overview

• Features:

  • Features 8x HDMI inputs which can be independently routed to 8x HDMI outputs
  • Supports 18 Gbps 4K UHD video including HDR, HDR10+ and Dolby Vision
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
  • Control via front panel, IR, RS-232 & TCP / IP
  • 3rd Party drivers available for all major home control brands
  • Advanced EDID management
  • HDCP2.2 compliant


• Specifications:

  • Video Input Connectors: 8x HDMI Type A, 19-pin female
  • Video Output Connectors: 8x HDMI Type A, 19-pin, female
  • Audio Input Connectors: 8x 3.5mm stereo jack (L/R)
  • TCP/IP Control: RJ45, female
  • Ethernet/Network: RJ45, female
  • RS-232 serial port: DB-9, female
  • Rack-Mountable: 2U rack height, rack ears included
  • Casing Dimensions (W x H x D): 17.3" x 3.4" x 11.1" (440mm x 87mm x 282mm) without feet
  • Dimensions Including Connections (W x H x D): 17.3" x 3.7" x 11.3" (440mm x 94mm x 288mm) with feet
  • Shipping Weight: 11lbs (5kg)
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature: -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 12V/6A DC


• Item Includes:

  • 1 x Custom Pro Hub Matrix
  • 2 x PRO-IN4HAB: 4 x HDMI2.0 Input with Audio Breakout
  • 1 x PRO-8IR-V2: IR pass-through card - for 2-way IR control, or IR control of matrix (8x8 chassis only).
  • 2 x PRO-OUT4H-V2: 4 x HDMI2.0 Output.
  • 1 x 24V/8A Power Supply
  • 1 x Remote Control
  • 1 x Rack Mounting Kit
  • 1 x Quick Reference Guide


• Warranty:

  • 3-Year Warranty
