Chauvet OVATIONE260CW Ovation Cool White Light - Light Engine Only with powerCON Power Cord - No Lens

OVATIONE260CW - Overview

• Features:

  • Cool white ERS style fixture with output exceeding a tungsten 750 W source
  • Ultra smooth 16-bit dimming, and 8-bit dimming curves to complement any lighting scheme
  • Flat, even field of light for superior gobo projection
  • RDM (Remote Device Management) for added flexibility
  • Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
  • Virtually silent operation for use in studio and theatre applications
  • Works perfectly with industry standard lens tubes and accessories


• Specifications:

  • Optical
  • Light Source: (CW) 198 W, (3.5 A), 5452 K, 50,000 hours life expectancy
  • Color Temperature (at full): (CW) 5452 K
  • CRI: (CW) 96
  • Beam Angle (w/14° lens): 11°
  • Beam Angle (w/19° lens): 13°
  • Beam Angle (w/26° lens): 16°
  • Beam Angle (w/36° lens): 20°
  • Beam Angle (w/50° lens): 28°
  • Beam Angle (w/15°-30° lens)(Narrow): 12°
  • Beam Angle (w/15°-30° lens)(Wide): 14°
  • Beam Angle (w/25°-50° lens)(Narrow): 21°
  • Beam Angle (w/25°-50° lens)(Wide): 22°
  • Field Angle (w/14° lens): 14°
  • Field Angle (w/19° lens): 18°
  • Field Angle (w/26° lens): 25°
  • Field Angle (w/36° lens): 34°
  • Field Angle (w/50° lens): 50°
  • Field Angle (w/15°-30° lens)(Narrow): 15°
  • Field Angle (w/15°-30° lens)(Wide): 29°
  • Field Angle (w/25°-50° lens)(Narrow): 26°
  • Field Angle (w/25°-50° lens)(Wide): 46°
  • Dimming Modes: 4
  • Lumens (w/19° lens): (CW) 9,530
  • Lumens (w/26° lens): (CW) 13,368
  • Lumens (w/36° lens): (CW) 13,184
  • Lumens (w/50° lens): (CW) 12,672
  • Illuminance (w/14° lens): (CW) 16,787 lux @ 5 m
  • Illuminance (w/19° lens): (CW) 10,674 lux @ 5 m
  • Illuminance (w/26° lens): (CW) 8652 lux @ 5 m
  • Illuminance (w/36° lens): (CW) 5185 lux @ 5 m
  • Illuminance (w/50° lens): (CW) 2181 lux @ 5 m
  • Illuminance (w/15°-30° lens)(Narrow): (CW) 19,900 lux @ 5 m
  • Illuminance (w/15°-30° lens)(Wide): (CW) 10,159 lux @ 5 m
  • Illuminance (w/25°-50° lens)(Narrow): (CW) 9,219 lux @ 5 m
  • Illuminance (w/25°-50° lens)(Wide): (CW) 3,468 lux @ 5 m
  • Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz

    Dynamic Effects
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Manual
  • Strobe Rate: (CW) 0 to 30 Hz
  • Dim Modes: 4
  • Built-in Automated Programs: Yes
  • Color Temperature Presets: (CW) No

    Construction/Physical
  • Dimensions (fixture only): 19.49 x 11.22 x 19.17 in
  • Dimensions (w/14° lens extended): 28.74 x 11.22 x 19.17 in
  • Dimensions (w/26° lens extended): 25.91 x 11.22 x 19.17 in
  • Dimensions (w/15°-30° lens): 32.87 x 14.61 x 14.61 in
  • Dimensions (w/25°-50° lens): 27.17 x 14.61 x 14.61 in
  • Weight (fixture only): 15.4 lb
  • Weight (w/14° lens): 20.8 lb
  • Weight (w/26° lens): 19.4 lb
  • Weight (w/15°-30° lens): 29.4 lb
  • Weight (w/25°-50° lens): 27 lb
  • Exterior Color: Black
  • Gobo Size (Optional): "A": 94 mm (outside), 79 mm (image), 2.5 mm (max. thickness)
  • Gobo Size (Optional): "B": 94 mm (outside), 69 mm (image), 2.5 mm (max. thickness)
  • Accessory Holder/Gel Frame Size (14° lens): 7.5 in (191 mm)
  • Accessory Holder/Gel Frame Size (19°, 26°, 36°, and 50° lens): 6.25 in
  • Accessory Holder/Gel Frame Size (15°-30° lens): 7.5 in
  • Accessory Holder/Gel Frame Size (25°-50° lens): 7.5 in

    Connections
  • Power Connection: Edison (Local) plug to Neutrik powerCON
  • Power Input: Neutrik powerCON
  • Power Output: Neutrik powerCON
  • Data Connectors: 3- and 5-pin XLR
  • Cable Length (power): 5 ft (1.5 m)

    Control
  • Control Protocol: (CW) DMX, RDM
  • DMX Channels: 1, 2, 3 or 6
  • Modes/Personalities: 4 personalities (1, 2, 3, 6)

    Electrical
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: (CW) 7 units @ 120 V; 12 units @ 208 V; 13 units @ 230 V
  • Power and Current: (CW) 225 W, 1.86 A @ 120 V


• GTIN:

  0781462215354
