Introducing the Fiberlink SDI Flex 3390 Series, one of the most versatile and capabable broadcast quality fiber optic products available today.
The SDI Flex 3390 Series allows you to transmit 3G, HD or SD-SDI as per SMPTE 424M-2006, 292 and 259 as well as DVB-ASI. If you have previously embedded audio or data into your SDI signal, the SDI Flex will retain the audio and data, bit-for-bit, throughout the entire transmission process.
In addition to pristine, broadcast quality SDI, the Fiberlink SDI Flex 3390 can transmit bidirectional audio, RS-Type data, Ethernet and even contact closure! Best of all, all channels are independent and available simultaneously!
And the SDI Flex 3390 is designed to be flexible in more ways than the signals it supports: Choose from ST or LC connectors, transmission over one or two fibers, and single mode or multimode to match your specific environment, requirements and budget.
To ensure signal intergrity, all signals are equalized prior to fiber optic transmission and re-clocked on the receiver. Both the transmitter and receiver are immune to pathological signals over the entire budget link and operating temperature range.
Available in card versions and a small footprint box version, it is ideal for broadcast or corporate studios, OB vans, rental and staging, auditoriums, stadiums and theaters, airport or transportation hubs, distance learning, surgical or medical imaging and more!
Please Note: Item shown is a box - a card will be provided in shipment.
