Datavideo SEB-1200 6 Input Switcher plus RMC-260 Controller Bundle

ITEM #: DV-SEB-1200 MFG #: SEB-1200

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$2,098.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


SEB-1200 - Overview

The Datavideo SEB-1200 Bundle combines the Datavideo SE-1200MU Switcher and the RMC-260 Controller into a powerful, ergonomic switching package. SE-1200MU along with the RMC-260, is the only 6-input production
switcher in the world that can switch over IP, computer interface or a control surface; all for under $2,000. SE-1200MU is the most affordable, versatile production switcher on the market which could be put in nearly any production application, including live events, worship, broadcast and education.

3 Types of Control
IP Control: SE-1200MU has the ability to stream its multiview in real-time to a PC for monitoring and controlling remotely. Designed to be fully controlled from any Windows Laptop/Mac with the included SE-1200MU software control interface.
Computer Control: Switch seamlessly between video sources and blend high-quality digital content on the fly using the SE-1200MU control interface (at no additional cost).
RMC-260 Control Panel: The RMC-260 is a customized switcher style controller. All keys on the unit are clearly defined for quick and easy operation.

SE-1200MU
Whether you are filming a seminar or conference, conducting a live outside broadcast or shooting inside a production studio, the Datavideo SE-1200MU HD video switcher enables you to switch seamlessly between video sources and blend high-quality digital content on the fly.

RMC-260
The RMC-260 is a switcher-style controller, an alternative to the PC Controller software of SE-1200MU, all keys on the unit are clearly defined for quick and easy operation.

  • Features:

    • SE-1200MU
    • Video Inputs: 4x HD-SDI, 2x HDMI
    • Video Outputs: 2x HD-SDI and 2x HDMI
    • Audio Inputs: 2x balanced XLR
    • Supported Resolutions: 1080i (50/59.94/60), 720p (50/59.94/60)
    • Video Processing: SDI: 4:2:2, HDMI: YUV 4:2:2, RGB: 4:4:4
    • Flexible Mix/Effects Processor with
    • - 2 Upstream Keyers, Chroma Key & Linear/Luma Key
    • - 2 DSK, supports Linear & Luma Key Modes
    • - 1 PIP (assignable to any of the 4 keyers)
    • - Wipe Generator: 32 Wipe Patterns
    • - Wipe, Mix & Cut Transitions
    • - Full M/E Preview function
    • Frame store (Up to 24 images Stored on SD card)
    • 10 Channel Multi-View (Only 1 HDMI/SDI monitor needed)
    • 12 User Memory Settings
    • Assignable Outputs
    • XPT (Cross Point Assignment)
    • Tally output: D-Sub 15pin
    • GPI output
    • 1U rack mount
    • Large ergonomic control surface with RMC-260

  • Specifications:

    • Total Video Inputs: 2 HDMI + 4 SDI
    • Total Outputs: 1 HDMI + 2 SDI
    • SDI Video Input: 4 (1080i /720p)
    • HDMI Video Input: 2 HDMI (RGB/YUV); 1080i / 720p
    • SDI Audio Output (PGM): 2CH
    • Analog Audio Input: 2CH XLR
    • Embedded Audio: HDMI & SDI
    • Internal Frame Synchronizers: 6 All Inputs
    • PGM Out: HDMI / SDI
    • Multi-view Out: HDMI (720p->720p ; 1080i->1080p); SDI (720p->720p ; 1080i->1080i)
    • Output can select any of input source: PROGRAM (w/ DSK); Clean PROGRAM, PREVIEW (w/o DSK), MULTISCREEN, Input 1~4
    • Audio Indicator on Multiview: Yes (output 2CH)
    • Tally Out: Yes
    • GPI: Yes (Level / Pulse Trigger selectable)
    • Software Updates: Ethernet

  • Item Includes:

    • 1x SE-1200MU product
    • 1x RMC-260 Controller
    • 1x AD Switch DC 12V
    • 1x Utility CD w/ CD Bag
    • 1x Thank You Card
